Actually, the sliding door mechanism on this model means it takes up a bit more floor space than a hinged-door unit — but what it does is give you a much tighter seal under high presure, which matters when you're running 134°C cycles and can't afford any steam loss.
We've had labs using teh 80L version for years with minimal issues; the AISI316L chamber option is usually worth it if you're sterilizing anything with trace salts or acidic residues, since 304 can pit over time.
Most buyers go with the 50L or 80L for biomedical work, and the working pressure sits at 0.23 MPa with a design temp of 144°C — that gives you good safety margin above the sterilization ceiling of 138°C, which is pretty much standard for prion decontamination.
CE and ISO13485 certs are current, and power supply can be either 220V or 380V depending on your facility (check your mains voltge before ordering). Lead time is roughly 25-30 working days form order, give or take a week depending on customs clearance.
We don't recommend these for continuous high-throughput production lines, though — the vertical design is better suited for batch sterilization of 35L to 100L loads, where you want consistent cycle validation across mixed loads of instruments and liquids.
The touch button interface is actually more reliable than the older membrane panels, and antidry burning protection kicks in automatically if the water level drops below the heating elements — a detail most buyers don't think to ask about until they've fried a unit.
We offer 35L, 50L, 80L, and 100L as standard volumes. Custom sizes outside this range aren't typically possible due to the fixed mold design, but we can adjust internal shelving to better fit your load if needed.
Our MOQ is 1 unit for the MDVC Series, so you can order a single machine for evaluation. Sample orders are welcome, and we can arrange a test run with your specific load if you provide the details.
Yes, the temperature is adjustable in 1°C steps across the full 105-138°C range. You can set it precisely via the LED touch button interface to match your specific sterilization protocol.
The autoclave is CE, EEC, and ISO13485 certified. We can share digital copies of the certificates and test reports upfront—just let your sales rep know. Hard copies ship with the unit.
It's packed in a plywood crate with foam lining to protect the stainless steel chamber and door mechanism during transit. For storage, keep it indoors in a dry, ventilated area between 5-40°C, and avoid stacking anything on top of the crate.
