We keep stock of more common sizes — 16mm² to 240mm² — in copper with PVC sheath, typical lead time is 3 weeks or so for anything else (check availability if you need aluminum conductor). Usually have around 500m per spec on hand for the 0.6/1kV rated stuff, but the higher voltage variants like 3.6/6kV get manufactured to order.
It handles the -15°C to +90°C range fine, most buyers go with teh 1.8/3kV rating for underground runs since it's a sweet spot between cost and protection. Bending radius is 12 times the cable diameter — that's tighter than some other armored cables we've dealt with, which helps in trench work. The XLPE insulation is pretty much the standard here for thermal stability, but what it does is reduce dielectric losses over long distances compared to PVC insulation. You can get it halogen-free with the LSZH option too, which matters for indoor industiral setups where smoke toxicity is a concern. Basically, if you're running it through a building with fire code restrictions, opt for that variant.
Not suited for direct burial without mechanicla protection — even though it's armored, steel wire or tape both do the job, but steel wire handles pulling tension better during insallation. We've had contractors prefer tape for fixed routes where bending is minimal, saves a bit on cost.
Cert-wise we've got CE and RoHS for EU compliance, plus ISO and CCC for other markets — COAs are included in the batch unless you ask for HPLC purity reports (which, honestly, aren't needed for power cable spec). 0.6/1kV is the baseline rating, but the 3-core version at 1.8/3kV is common for industrial machinery feeds. Color is black only, no custom colors.
Our MOQ for this YJV cable is 500 meters per size, but we can combine multiple sizes into a single order to hit the total. Just let us know the breakdown when you inquire.
Typical lead time is 2-3 weeks for a 10,000-meter order, depending on the specific size and core configuration. We can expedite shipping via air freight at an extra cost if you need it sooner.
Yes, we can send you copies of the CE and RoHS certificates, along with the ISO and CCC documents, right after order confirmation. Just request them from your sales rep.
We don't stock 4-core as standard, but we can produce it as a custom order. The minimum for custom cores is usually 2,000 meters, and it adds about a week to the lead time.
Store it in a dry, shaded area with the reel upright, away from direct sunlight and moisture. If kept between -15°C and +35°C, it stays good for at least 10 years without degradation.
Upon receiving our bulk order of the YJV model XLPE insulated copper conductor electric cables, I must express my utmost satisfaction with the overall experience. The delivery was incredibly prompt and well-organized, arriving ahead of schedule without any delays, which is crucial for our project timelines. The packaging was robust and secure, ensuring that all items were in perfect condition upon arrival, with no signs of damage or mishandling. In terms of quality, the cables appear to be manufactured to high standards, with excellent craftsmanship evident in the insulation and conductor materials, giving us confidence in their durability and performance. Customer service was outstanding throughout the process; the team was responsive, professional, and went above and beyond to address our inquiries and provide timely updates. Overall, this has been a seamless and reliable transaction, and I would highly recommend this supplier for their efficiency and attention to detail.
Highly satisfied with the delivery speed for this bulk order; the cables arrived ahead of schedule and were well-packaged to prevent any damage. The quality appears excellent, with sturdy insulation and proper certifications clearly visible, ensuring reliability. Customer service was responsive and helpful throughout the process, addressing all queries promptly. Overall, a smooth and efficient experience from start to finish.
Quick delivery and excellent packaging ensured the cables arrived in perfect condition without any delays. Quality-wise, the materials feel robust and durable, meeting all specified standards. Service was outstanding, with prompt responses and helpful support throughout the ordering process. Overall, a very satisfying experience that I would highly recommend to others.
