Custom DCU10 Animal Ultrasound Machine with B/M/Color/PDI/PW Modes for Comprehensive Exams

The DCU10 Veterinary Color Doppler Ultrasound System is designed for professional animal diagnosis across multiple applications including abdomen, heart, gynecology, obstetrics, urology, small organs, pediatrics, and blood vessel examinations.

Equipped with a high-resolution 15" LCD display, the system provides clear imaging with multiple display modes including B, 2B, B+M, 4B, M, B+Color, B+PDI, B+PW, B+Color+PW, and B+PDI+PW. The B+C/PDI Double Real Time mode enhances diagnostic capabilities.

The system utilizes full digital imaging technology with pulse inverse harmonic composite imaging, multi-beam synthesis, space compound, and image enhancement noise reduction for superior image quality.

Multiple probe options are available including convex probe (3.5MHz), linear probe (7.5MHz), cavity probe (6.5MHz linear rectal), and micro-convex probe (6.5MHz), with frequency range from 2.5-10.0MHz.

The multi-lingual operating system supports Chinese, English, and Spanish, with additional language options available. The system features full-screen annotation input in both Chinese and English, including Wubi input method support.

A comprehensive measurement calculation software package covers abdomen, gynecology, obstetrics, small organs, heart, and blood vessels, providing precise results for various medical fields.

Advanced image parameters include gray scale mapping (≥15), noise suppression (≥8), frame correlation (≥8), edge enhancement (≥8), and image enhancement (≥5). The system offers adjustable scan density and image flip options with maximum scanning depth ≥320mm.

Detailed measurement capabilities include routine B/C mode measurements (distance, area, perimeter, volume, angle), M mode measurements (time, slope, heart rate), and Doppler mode measurements (velocity, resistance index, pulse index). Specialized obstetrics measurements cover multiple animal species.

The standard configuration includes the main unit, 15" LCD monitor, 6.5MHz micro-convex probe, 7.5MHz linear probe, inverse harmonic imaging, PDI mode, spatial composite imaging, and built-in workstation.
