When your custoemr's packaing line is running 8 to 20 cartons a minute for cosmetics or beverages, they can't afford jams or misaligned tape — this DPF series handles that range without breaking a sweat, and it adjusts for cartons form 150mm up to 600mm in length and height.
It uses stainless steel and aluminum alloy, so it holds up in a wet cleaning products enviroment, and the tape width can be 48, 60, or 75mm depending on your box flap configuration — we usually stock the 60mm option.
Power draw is only 180W to 400W on 220V single phase, which is pretty low for a fully automatic unit, and working height sits at 650mm give or take 50mm to fit most conveyor lines.
What makes it reliable is the combination of CE and ISO certs with components from known international brands — you don't get that with every budget sealer, and maintenance is straightforward because the design doesn't bury wear parts.
Air consumption runs 250 to 450 NL/min at 5-6 MPa, so check your compressor capacity before ordering — this isn't suited for small shops with a portable unit, basically you need a real air supply.
our company can customize it with a carton erector or labeling station, but lead time varies (usually 20 days or so) depending on options — most buyers go with the DPF-60 for medium runs, and we confirm stock before quoting.
MOQ is typically 1 unit, but we can discuss bulk orders if you need multiple machines.
Standard lead time is around 15-20 working days, depending on current production load.
Yes, both CE and ISO certifications are included, so you’re covered for international standards.
Absolutely, the minimum size is L150×W150×H150mm, so that fits perfectly.
We usually suggest 60mm tape for beverage packaging, but 48mm and 75mm options are also available.
