Usually we stock this model, but the 15-box-per-minute rate holds steady once you dial in the box size — the KX4540 adjusts from 250 to 450 mm in length, 150 to 400 mm in width and height. Takes about 20 days or so from order to dock, depending on the voltge you need (220V or 380V, both 50Hz). Weighs 500 kg, so you'll want a forklift and a solid floor.
It's fully automatic, so what it does is form and bottom-seal cartons in one pass, no operator doing the folding. The stainlss steel build means it works in food or pharma lines without rust worries, and the tape width can be 48mm, 60mm, or 75mm — pick one when ordering because the setup varies. 0.3 kW power draw is pretty low for a machine this size, barely bumps your electrcial load.
That 2000×1900×1450 mm footprint — check your line clearance before you buy, because of that it's wider than some erectors. Most buyers go with the 48mm tape for general use, but if you're sealing heavier boxes, the 75mm gives a better hold at the bottom seam. A detail you might not think to ask: the self-correcting mechanism keeps right angles consistent even if cardboard is slightly warped from storage.
It's not designed for irregularly shaped cartons or ones with die-cut inserts — you need a standerd RSC or similar blank for this to run smooth. A concrete thing from running it: the tape head jams less often if you keep the machine level within 2 degrees, so shim the feet if your floor isn't flat. CE and ISO9001 certified, so your auditor won't push back, but our company can't promise SGS paperwork arrives same time as teh machine (usually 2-4 weeks to get the hard copy).
Yes, the KX4540 maintains that speed across the full size range. Smaller boxes tend to run at the upper end, while the largest ones might dip slightly, but you'll still get consistent throughput.
It's ISO9001, CE, and SGS certified. We'll send you PDF copies of all certificates before shipment—just let us know if you need them notarized.
The machine supports 48mm, 60mm, and 75mm tape widths—just swap the tape holder. No modifications needed, so you can switch between sizes as your packaging changes.
Standard lead time is 15-20 working days from order confirmation. It comes with a 2-year warranty covering parts and labor for manufacturing defects.
Absolutely—the full stainless steel body meets hygiene standards for pharma and food environments. It's easy to sanitize and resists corrosion from cleaning agents.
