We’ve shipped quite a few of these to operators who need something that can actually handle a 400-meter depth without bogging down, and the 18-ton lifting force is what usually gets their attention first—it’s not just a number on paper, because the triplex pump setup (Bormak50+50+25) and the 305+305 rotary motor actually deliver consistent torque in the 6500-9000 range under load.
You’ll want to confirm teh lead time, but we typically have these ready in about 30 days or so form order, and we can do the OEM/ODM branding if your company logo or color scheme is needed—just send us a vector file and we’ll handle the decals and paint before crating.
The Yuchai 4-cylinder 72 kW engine is pretty much standerd for this class, but it’s not high-rev unit; it’s built for sustained torque at lower RPMs, which matters when you’re running a 203mm diamond bit through harder formations, and the 4.2-meter lifting height gives you decent clearance for rod handling on most truck beds.
Payment terms are typically 30% deposit with the balance before shipment, and our company can do T/T or L/C at sight—though for first-time buyers we usually ask for a confirmed LC or 50% upfront, just to keep things clean on both sides, and we’ll provide the ISO 9001:2008 cert and a full COA for the triplex pump and motor assembly.
It’s not ideal for shallow residential water wells under 50 meters—overkill, really, given the 10.5-ton weight and the 6200×1950×2500mm footprint—but for mining exploration or geothermal loops where you need the 165-350mm diameter range and the 18-ton pullback, it’s actually better than most imported rigs at twice price.
We can include a spare set of seals and a basic tool kit with the crate, but the rotary torque specs (6500-9000 Nm) are measured at the spindle, not the bit face, so factor in about 10-15% loss depending on your drill string length.
We typically require a minimum order of 1 unit for standard configurations, but we can discuss smaller orders if you're just testing the waters. For custom builds, MOQ might vary depending on the changes.
Standard units usually ship within 30-45 days after order confirmation. Custom orders may take a bit longer, depending on the complexity of the modifications you need.
Yes, we include both ISO 9001:2000 and ISO 9001:2008 certificates with every machine. We can also supply additional quality documents like material test reports if required.
The 18 tons lifting force is the rated capacity at the winch, not depth-dependent, so you get that pull throughout the 400 meter depth. It’s enough to handle standard diamond bit drilling without issue.
We ship it fully assembled or partially knocked down in a steel frame crate, depending on your port. Store it indoors or under a covered area to protect the Yuchai engine and triplex pump from moisture.
