Factory Supply Heatflow 4 Bathroom Heating System with 1100-2000W Power and Ceiling Installation

We’ve got about 200 units in the warhouse right now, so stock isn’t an issue, and shipping typically takes 20 days or so once the order is confirmed—air freight can be faster if you need it, but sea is the norm for these. The 35W motor handles the ventilation side well, pushing 270 m³/hr through side ducted setup with that 3m flexible pipe included, which is pretty much standard for most residential installs. You’ll want to check your ceiling depth before ordering though—it needs a minimum of 250mm clearance, otherwise the unit won’t sit flush.

Actually, the heating comes from four 275W infrared bulbs, so total power sits between 1100 and 2000W depending on how many lamps you run at once, and that’s enough for medium to larger bathrooms—I’ve seen it struggle a bit in open-plan spaces above 15 square meters, so keep that in mind. The infrared heat is instant, no warm-up time, which is what most buyers go with because it’s efficient for quick bursts. What it does is heat objects and people directly rather than the air, so you feel it right away even with the fan running.

IPX2 rating means it’s splash-proof but not for direct water spray, so it’s fine for ceiling installation in a bathroom zone 2 or 3—don’t use it over a shower or bathtub without additonal shielding. The 8W LED light puts out 1000 lumens at 4200K neutral white, which is a nice touch for general lighting, though it’s not dimmable if that’s something you were hoping for. Silver and gold are the only color options we carry; gold tends to sell slower but some buyers prefer the warmer look.

We include a wall switch with each unit, but you’ll need to wire it into your existing setup—no plug-and-play here, so an electrician is recommended unless you’re comfortable with that. The ducting is side-ducted with a 120mm flexible hose, 3 meters long, which gives you some flexibility in routing but ideally keeps the run short to maintain airflow. One detail that rarely comes up but matters: the ceiling plate dimensoins are 400x360x180mm, so measure your opening before drywall.

Certifications are SAA, TUV, CB, CE, RoHS, and EMC—basically all the common ones for Australia, Europe, and some Asian markets, so you’re covered for most regulatory checks. We usually have stock, but if you’re ordering more than 50 units, confirm lead time because we sometimes have to pull form the next production batch. The motor power is 35W, which is pretty typical for this class of heater-vent combo, and the whole unit weighs roughly 4.5kg or so, easy enough for one person to handle.

Anyway, for an order, just let us know quantiy, color preference, and whether you need standard packaging or custom branding—our company can do that for larger MOQs, usually 100 units or more. We’ll send a proforma invoice with shipping options and payment terms once our company have those details. The COA and SDS are available on request, but we don’t include them automatically unless specified.
