Basically it's an RCBO that handles overload, short circuit, and residual current all in one DIN-rail unit, and we ordered it because of that it covers the full range form 1A all the way up to 63A depending on what you need.
The 30mA residual current setting is standard and that's what most buyers go with for general protection, though you can get other values customized if your setup requires something different.
It's 230/400V AC at 50/60Hz and comes in 1, 2, 3, or 4 pole configurations, with breaking capacity at 4 or 6kA depending on the variant — we usually stock the 6kA version since it's tighter tolerance than most for commercail installs.
Mechanicla life is rated at 10,000 operations and the housing is flame-retardant PA66 nylon, which holds up better than cheaper ABS alternatives in warmer environments (operating range is -25°C to +60°C).
One thing you might not think to ask: teh screw terminals are standard but they're not the largest, so if you're running heavy-gauge wire you'll want to check the terminal capacity first.
Also, it's not suited for outdoor panels without additonal enclosure protection since IP20 is basically just basic dust and finger protection, not water-resistant.
You can choose from 1A, 3A, 6A, 10A, 16A, 20A, 25A, 32A, 40A, 50A, or 63A. Just let us know which value fits your load when ordering.
30mA is our standard for this model, but we can customize the residual current setting to other values if your project needs something different. Just ask.
It's certified with CE, CB, ISO9001, and CCC, and complies with IEC60898 and GB16917.1 standards. You'll get full documentation with your shipment.
Our MOQ is typically 100 pieces per model, but we can negotiate lower quantities for first-time orders or sample requests. Just reach out.
Yes, we offer 1, 2, 3, and 4-pole versions. All mount on a standard 35mm DIN rail, so installation is straightforward in any standard distribution board.
