Actually ran into this when a customer needed to drive a small centrifugal pump at a remote site with only single-phase power avaliable—three-phase wasn't an option and they couldn't justify a VFD just for one motor, so the dual-capacitor starting method on this YL series handles the high inrush torque for the pump impeller without tripping breakers, which is the main headache we've seen with cheaper single-phase motors.
Power range is 0.25HP to 5HP, so roughly 0.18kW to 3.7kW, and at 110V or 220V ±5% with both 50Hz and 60Hz compatibility—most buyers go with the 1HP or 2HP for food machines and power tools, but the 0.25HP is pretty much only used for small fans or light-duty appliction where a smaller frame is easier to handle.
Speed varies between 1400 rpm and 2800 rpm depending on pole configuration, though we usually have stock in the 1400 rpm range for pump work because that's where the torque curve is flatter at startup. Insulation class is B or F (the F-rated ones are better for continuous operation in warmer ambient conditions, say above 30°C), and protection class is IP44 or IP54—just keep in mind the IP54 is sealed better for dusty environments but still not submersible, so don't put it in a washdown area. Cooling is IC411 with an external fan, and duty is S1 continuous, so it's fine for running all day on that pump application—no need to worry about thermal cycling.
Housing is either aluminum or cast iron depending on the size—aluminum for the smaller frames under 2HP keeps weight down, but cast iron is standard for 3HP and up because it dampens vibration better on food processing equipment where noise matters. The rotor uses 45# steel, windings are 100% copper (no aluminum windings here, which is good for longevity), and bearings are C&U brand, which is a decent standerd Chinese brand—nothing fancy but they hold up for a few years under normal load.
Efficieny sits at 72-78% and power factor at 0.92-0.95, so it's not going to win any energy awards, but for a single-phase motor in this horsepower range, that's actually tighter tolerance than most competitors offer—we've tested a few that struggle to hit 70% at full load. Ambient temp range is -15°C to 40°C and altitude limited to 1000m or so, so don't try this at high elevation without derating, and CE and ISO9001 certs are in place for export—though I'd confirm the COA if your inspector is picky about the exact voltge tolerance on the nameplate.
Anyway, the dual-capacitor design is what makes it work for that pump start—without it you'd need a bigger motor to handle the locked-rotor current, and space was tight in the enclosure.: the 0.25HP model has a slightly lower starting torque than the rest of the range, so it's not suited for anything with a heavy inertial load like a large fan blade or compressor—stick to the 0.5HP or higher for those.
You can choose between aluminum or cast iron. Aluminum is lighter and good for portable equipment, while cast iron is more durable and better for heavy-duty industrial applications where vibration or heat is a concern.
Our MOQ for the YL Series is typically 10 units per model, but we can discuss lower quantities for trial orders or first-time buyers. Just let us know your needs.
Yes, CE and ISO9001 certificates are included with every shipment. We can also provide test reports for each motor batch if requested.
Yes, it's designed for dual frequency operation at 50Hz and 60Hz. Just make sure the voltage matches your local supply within ±5%, and the speed will adjust accordingly within the 1400-2800 rpm range.
Lead time is usually 15 to 25 working days, depending on the quantity and housing material choice. Custom specs might add a few extra days, but we'll confirm once you place the order.
