The XF20A Notebook Ultrasound Scanner is a versatile medical imaging device designed for professional diagnostic applications. With its compact notebook-style design, this ultrasound scanner offers portability without compromising on performance.
This advanced ultrasound system features three different probes: a 3.5MHz/R60 convex array probe, 6.5MHz/R13 dimpling array probe, and 7.5MHz/L40 line array probe. Each probe offers specific imaging capabilities suitable for various diagnostic requirements.
The scanner provides multiple display modes including B, B/B, 4B, B+M, and M modes, with image multiplying factors ranging from x0.8 to x2.0 depending on the probe used. The system includes advanced image processing features such as γ correction, frame correlation, digital filtering, and edge enhancement for superior image quality.
Key measurement functions include distance, circumference/area, volume, heart rate, gestational weeks calculation, and expected date of confinement. The annotation function allows for hospital name, patient information, and 64 body marks with probe position indicators.
The XF20A features frequency conversion capability with five frequency periods (2.5MHz to 5.0MHz) for the convex array probe and additional high frequency options (5.5MHz to 7.5MHz) for specialized probes. The system includes 8-segment TGC control and overall gain adjustment for optimal image optimization.
Additional features include image polarity adjustment, 256-image cine loop memory, image playback options, and permanent storage for 128 images. The device offers multiple output interfaces including VGA and PAL video outputs, as well as USB connectivity for image storage and transfer.
The standard configuration includes the host machine, one 3.5MHz convex array probe, power adapter, 11.1V 3000mAh Li battery, and USB port. The system is CE certified and complies with ISO13485 standards for medical devices.
