Customizable SL500S Tracked/Mounted Drilling Rig for Mining and Construction Projects

The SL500S drilling rig is a high-performance hydraulic rotary drilling machine designed for various geological conditions. With a maximum drilling depth of 500 meters and hole diameter range of 105-400mm, this rig is ideal for water well construction, geothermal exploration, and mineral prospecting.

The rig features a powerful 110kw Yuchai diesel engine and advanced hydraulic system that allows precise control of rotation speed (75/150rpm) and torque (11000/5500Nm). The modular design enables quick conversion between different drilling methods including DTH hammer, rotary, and mud drilling.

Key performance characteristics include:

• Adjustable rotation speed and torque for different formations
• Hydraulic feed system with 48-55m/min feed speed
• Tracked or truck-mounted chassis options available
• Compatible with medium/high pressure DTH hammers
• Optional mud pump and foam injection system

The robust construction uses high-strength low-alloy steel for durability in harsh conditions. The rig's compact dimensions (6.52×1.85×2.51m) and 21° climbing ability make it suitable for challenging terrains. With 2000 hours warranty and CE certification, the SL500S delivers reliable performance for professional drilling operations.
