Look, the 3000x1500mm working area sounds huge, but you're not going to be 14mm carbon steel at full speed with a 500W laser — that's the reality, but for most sheet metal jobs up to 6mm or so, it's actually pretty fast and the 60m/min max speed with 1.2G acceleration means cycle times are tight.
We've had buyers who tried cheaper machines with that 3000mm pipe option and the square tube range of 20-80mm — what it does is handle both sheet and pipe on one frame, so if you're switching between flat parts and tube frames, you don't need two machines, but the round pipe max is only 120mm so don't plan on heavy structrual tube.
The ±0.02mm repeat accuracy is better than most gantry-style cutters in this price bracket, and the Yaskawa servos paired with Cypcut control mean you can actually hold that tolerance across the full 1500mm width — not just in the center where everything looks good on paper.
380V power supply is standard, and the water cooling system keeps laser stable even on 8-hour shifts stainless at 4000W, though if you're doing mostly thin galvanized under 2mm, the 500W or 1000W option saves you on initial cost and still cuts clean.
Lead time is about 30 days or so for teh 3000x1500mm model with standdard 1500W laser, but if you want the 6000mm pipe option or a higher power like 3000W, add another 2 weeks — we usually have stock on the base configuration, but confirm before ordering.
One thing nobody asks about is the chip tray design — the LX3015E has a removable slag drawer under the bed, which saves you form crawling under the machine with a shovel, and that's a detail you'll appreciate after the first week of production.
Yes, it can process round pipes from Φ20 to 120mm and square pipes from 20 to 80mm. The maximum pipe length is 3000mm, with an optional 6000mm version available.
We typically accept orders starting from 1 unit, though MOQ may vary slightly depending on the laser power option you choose. Just let us know your preferred wattage.
Yes, the LX3015E comes with CE, ISO, and SGS certifications. We can include copies in the shipment or send them electronically before dispatch.
Lead time is typically 15-20 working days after order confirmation, depending on stock and the specific laser power. Higher wattage models may require a few extra days.
The LX3015E is packed in a wooden crate with foam padding to prevent damage. It should be stored indoors in a dry, dust-free environment with temperatures between 5°C and 40°C.
