That insertion loss figure of 0.2dB or less is better than what you'll typically see with field-terminated connectors where you're relying on good cleave and polish—we're talking tighter tolerance than most pre-polished sleeves on market, and it holds over 1000 mating cycles which basically means you don't have to worry about degrading performence after a few swaps in a patch panel or junction box.
So the ABS housing with that PC inner ferrule is IP54 and IP58, which pretty much handles indoor splashes and outdoor dust without needing extra boots or shrink tubing, and the operating range goes from -40°C right up to 85°C (storage can take 120°C for shiping) so you're covered for rooftop cabinets or those unventilated MDF closets where it gets toasty in summer.
We've seen buyers who tried cheaper knockoffs with unknown polymer blends; what happens is the anti-pulling force drops to under 100G after a few temperature cycles, but these hold 200-600G consistently, and the vibration test shows less than 0.1dB shift even at 60Hz with 1.5mm amplitude—that detail alone saves you callbacks on 4G small cell deployments where antenna cables get jostled.
One thing people don't think to ask is the matrial's UL 94V-0 flame rating; for any telecomm network that goes into plenum spaces or riser shafts, having that certifcation baked into the connector body means you're not adding a fire risk just because you wanted a quick termination. Actually, the 5L drum is easier to handle if you're ordering in bulk—no, wait, that's the epoxy reference, but anyway the package size is compact at 10x15x10 cm per 50 units or so.
And we keep stock on the SC-UPC variants for 4G and wireless LAN applicators because those are the ones most common, but confirm the lead time if you need FC-ST or hybrid adapters—those sometimes run 20 days or so depending on the batch composition.
Not suited for high-vibration rail or military comms where you'd want a locking bayonet, but for standard telecom collocation rooms and fiber-to-the-antenna setups, this hits the sweet spot on price and reliability without chasing specs you don't actually need.
MOQ is typically 100 pieces, but we can work with smaller trial orders. Lead time is usually 7-10 working days for standard orders.
Yes, it's fully certified with CE, ISO, RoHS, and GS. We include the relevant certificates with each shipment or upon request.
IP54 is dust-protected and splash-resistant, while IP58 is dust-tight and can handle continuous immersion. We can supply either based on your environment.
The standard PC housing is rated for -40°C to +85°C operation. For higher temps, we'd need to discuss material options, but this might affect lead time and cost.
Each connector comes in a 10×15×10 cm box, individually wrapped. Store at -40°C to +120°C in a dry place to ensure the 1000-cycle durability holds up.
