Usually stock a mix of these across ICU and step-down units—depends on how many active vents you need online at once, some run it primarily for lower tidal volume work around 300ml, others push it to the full 1500ml for adult trauma.
Tidal volume range 50-1500ml, rate 6-60 bpm, I:E ratio 1:1.5 up to 1:3—give or take we see most buyers targeting around 400-600ml for routine adult ventilation and it handles that well, pressure trigger goes -4 to 10 cmH2O, flow trigger 1-10 L/m.
It's got A/C, SIPPV, IPPV, SIMV, IMV, and MANUAL modes, basically any mismatch you'd see with standerd ICU patients—the SIMV rate ranges from 1-12 bpm, max pressrue is capped at 6.0 kPa (so it's not for high-pressure pediatric cases), inspiratory plateau adjustable to 50% of inspiratory time.
High visibility LED display (not touch, which we've had some buyers prefer for sterile wipe-downs), 9-level adjustable humidifier baked in—pretty much you get teh primary unit, power cord, backup battery good for 4 hours, and a manual—no extra tubing or masks, those are sourced seprately.
CE, FDA, ISO13485 certs on file, meets IEC 60601, roughly 15kg weight so it's not too bad to wheel between bays, power is AC 220V/50Hz only—if your facility runs 110V you'll need a step-up transformer, check lead time on that.
MOQ is 10 units. Lead time is typically 15-20 working days after order confirmation, depending on customization needs.
Yes, we include copies of CE, FDA, and ISO13485 certificates with each order. You'll get them in the shipping documents.
You can set and lock the tidal volume at any value between 50-1500ml. It stays at that setting until you change it manually.
The ventilator is packed in a reinforced carton with foam inserts and a waterproof liner. It's designed to withstand international shipping without damage.
The backup power is built-in as a rechargeable battery, providing at least 4 hours of operation. It can't be upgraded, but you can connect an external UPS for longer runtime.
