We've been moving these units for almost eight years now, and it's basically the workhorse for any hospital's ICU or ER setup where you need relaible respiratory support for neonates up through adults, and what always gets attention is that 10.4-inch TFT LCD screen that shows everything—waveforms, alarm logs, all the parameters—without needing to dig through menus.
The tidal volume goes from 20mL all the way to 1500mL, and you can dial the frequency from 1 to 100 bpm, plus the I:E ratio adjusts from 4:1 down to 1:8 so it handles pretty much any ventilation strategy you throw at it, but buyers should know it's not really suited for transport given the 17kg net weight and the 560×560×615mm footprint.
So for the more critical cases, the PEEP maxes out at 20 cmH2O and you can set oxygen concentration anywhere between 15% and 100%, which matters more than you'd think when you're managing ARDS patients or weaning protocols, and the three-level alarm system catches high/low pressrue, apnea, and disconnection imediately.
220 volts at 50 hertz is standard power supply (1-2 Hz tolerance baked in), and we typically sell it with a COA from the factory that shows the flow sensor calibration data—confirm ahead of time if you need a specific HPLC or TDS report since those aren't included by default.
Most buyers go with the manual mode as a backup during power outages or high-flow scenarios, actually, and we always keep about 20 units or so in stock for immediate turnover, but the MOQ is 5 pieces if you're looking at a larger facility order—check lead time for anything over 10.
Our standard MOQ is 10 units per model, but we can negotiate smaller batches for first-time buyers or trial orders.
Yes, we can supply CE and ISO13485 certificates upon request. FDA registration is available for specific markets—just let us know your target region.
Absolutely, the tidal volume range starts at 20mL, so it's fully adjustable for neonates and infants. You can fine-tune it in 1mL increments.
Typical lead time is 15–20 working days after order confirmation and payment, depending on current production load.
Store it in a clean, dry environment between 10°C and 40°C, away from direct sunlight. Keep the original packaging intact to protect the LCD and sensors.
