Wholesale OEM Anti Drone Defense System Module with 47dBm Gain

We've got about 200 units in stock right now, but lead times jump to 6 weeks once those move, so confirm timing before you commit. Shiping's straightforward at 0.25kg and that compact 153×38×20mm form factor—no cold chain worries obviously, just standard courier with proper RF shielding packaging. The SMA output interface means you'll need to match your antenna cables yourself, usually standard RG316 or similar.

What makes it worth buying is the 50W output at 47dBm gain in that frequency range (5150-5350MHz), which pretty much covers common consumer drone bands. Harmonic suppression hits at least 11dBm and clutter suppression runs above 65dBm, so false positives on jamming are significantly reduced versus cheaper modules we've seen. Working current under 4A at 24-27V power supply means you can run it off a standard drone battery setup or regulated bench supply.

Typical buyers go with the OEM version for fixed-site countermeasures where you need reliable drone neutralization over wide areas—it's not suited for handheld or moving platforms due to heat dissipation at sustained full output. We've noticed most clients pair it with a directional antenna for specific perimeter coverage rather than omnidirectional, basically because the gain profile favors concentrated jamming.

Operating tempearture from -25°C to +55°C so it handles outdoor enclosures fine in most climates, but you'll want active cooling if running continuous duty above 45°C ambient. The 4A max draw is at full output, but in practice pulsed duty cycles can cut that by about 30% depending on your firmware.

CE, ISO, RoHS, and GS certified—this isn't regulatory hassle, it's already baked in for EU and most export markets. One thing we usually mention: the clutter suppression number (≥65dBm) is often misread as a spec sheet boast, but it actually translates to cleaner signal isolation in urban environments where reflections kill cheaper modules.

MOQ is 10 units for wholsale, and our company offer pricing drops around 50 unit orders or so. Just be upfront about whether you need custom frequency tuning—the PA 5150-5350MHz variant is locked to that band, but we've done 4.9-5.8GHz re-tunes for special projects if volume justifies it.
