You're likely handling stainlss or carbon steel most days, maybe aluminun or copper when it's tricky—this machine runs 1080nm wavelength from a QBH interface, air-cooled so no chiller maintenance, and the swing width goes 0-4mm with frequency from 0-300Hz across 32 craft groups.
We've got the continuous or pulsed mode to pick from depending on the job, and what you'll find is the 1500W output handles up to about 4mm plate in a single pass for most mild steel—aluminum usually needs a second pass or preheat, though. It's basically a 10m fiber cable that gives you room to walk around a frame or reach into a corner without dragging the whole unit.
The thing weighs under 45kg, which is pretty much why we see fabricators taking it up on scaffolding or into tight bays where a cart won't fit. Dimensions are 65×35×60cm, so it'll sit on a workbench or in the back of a truck, but the magnesium alloy housing means it's not indestructible—don't drop it off a lift.
One detail you might not think about: the 32 craft groups let you save settings for different materials or joint types, so when you switch from 2mm stainless to 3mm brass, you're not dialing in everything fresh each time. It's better than most handheld units for this because the swing frequency range is wider than typical 200Hz caps.
Input voltage is 220V at 16A, 50/60Hz, so standard shop power works—just make sure your breaker isn't shared with a big compressor or it'll trip. When ordering, you get the welding head, the 10m fiber cable, a protective lens kit, and a carrying case that's usually included but double-check listing for your region (lead time runs about 20 days or so from our warhouse).
You can weld up to about 3-4mm on mild steel in a single pass, and around 2-3mm on stainless or aluminum. Deeper welds are possible with multiple passes or edge prep.
Yes, we provide CE and FDA certification documents with each unit. Just let us know which standard you need for your region, and we'll include it in the shipment.
We accept single-unit orders for this model. No MOQ restrictions, so you can start with one machine to test it out.
Standard lead time is 7-15 working days. The swing width is adjustable from 0-4mm, and we can preset custom parameters in the 32 groups if you need specific settings for your application.
Yes, the air cooling handles continuous operation well for most jobs, but we recommend taking a 10-minute break every hour if you're running at full power. It keeps the laser source stable and extends the lifespan.
