Basically needed something that could manage both O2 and air without separate gas blending—this one does that via microprocessor control and it’s got a decent backup battery for about 4 hours, so we don’t hit total downtime during a power hiccup, though we usually have stock to confirm lead time since the 35kg weight means shipping can be tricky.
The tidal volume range is 50 to 1500ml, which covers adult and pediatric cases, and the respiration frequency goes form 1 to 99 bpm, though most buyers go with the 8–20 bpm range for typical ICU use—it support A/C, IPPV, SIPPV, IMV, SIMV, PEEP, SIGH, SPONT, and MANUAL modes, but it’s not suited for neonatal work because the minimum volume is too high.
Display is a 10.4-inch TFT—clear enough for real-time monitoring during setup—and there’s a humidifier with tempearture adjustment, which is useful for longer ventilation sessions (usually 2-4 weeks of continuous use), but the max safe pressure of ≤6.0kPa is a hard limit you need to respect; it’s tighter than some older units.
CE and ISO13485 certs are there, which I checked against our compliance requirements, and the warranty runs two years—one detail to note is that the 220V 50Hz power supply isn’t universal, so you’ll need a transformer if your mains are different, and the dimnesions are roughly 760mm by 600mm by 420mm, so make sure the cart fits.
And the oxygen concentration spans 21% to 100%, which is pretty much standerd for ICU work, but I also noticed MOQ is one unit and the suppiler provided a COA with each shipment—confirm lead time because we ordered a few spares and got them in about 20 days or so, give or take a few days base on customs.
Anyway, it’s a solid choice for general ICU breathing support—I’d avoid it for transport because of the 35kg weight and lack of integrated compressed gas cylinders, but for bedside use with the backup battery, it covers most scenarios.
Our standard MOQ is 5 units per order, but we can negotiate for smaller trial orders if needed.
Yes, we include both CE and ISO13485 certificates with every shipment, along with a full quality inspection report.
Absolutely, it supports adult and pediatric patients. Tidal volume ranges from 50 ml to 1500 ml, so you can adjust it per patient needs.
Typical lead time is 15–20 working days after order confirmation and payment, depending on stock availability.
Yes, the built-in backup battery provides up to 4 hours of operation at normal settings, which covers most power outage scenarios.
