What really sets it apart is the 0.65-second take-out time—that's faster than most operators can blink, and it'll shave seconds off each cycle on a 50-850T press.
We've got AC servo drives on all axes for ±0.1mm repeatability, vertical stroke form 700-1400mm, and the arm handles 5-15kg load, so it's fine for mold release up to medium-sized parts.
The micro-computer controller has a teaching function and jig circuit built in, plus you can add pneumatic scissors or a spray system as options—just check lead time on those (usually 2-4 weeks).
Basically, most buyers go with single-stage arm for 300T and under, but teh telescopic version gives you more reach on bigger molds without increasing floor space.
It's not suited for cleanroom environments because the servo motors aren't sealed, and that's just a fact—but for standdard injection shops, it's better than any pneumatic unit we've seen at this price point.
We typically require a minimum order of 1 unit for standard models, but if you need a custom configuration with optional features like a spray system or pneumatic scissors, we may ask for a MOQ of 5 to 10 units depending on the complexity.
For a standard single-stage arm with a 1400mm vertical stroke, lead time is usually around 15 to 20 working days. Custom builds with optional circuits or spray systems can add 5 to 10 more days.
Yes, every unit comes with both ISO and CE certification documents. We can also include a material compliance report or a calibration certificate for the positioning accuracy of ±0.1mm if your quality team requires it.
The minimum take-out time is fixed at 0.65s based on the AC servo motor and mechanical design. Going lower risks part damage or reduced positioning accuracy, so we don't recommend it. The dry cycle time can be optimized down to 5s with proper programming.
We pack it in a plywood crate with foam padding to protect the servo motor and controller during transit. For storage, keep it in a dry environment between -10°C and 50°C, and avoid stacking anything on top of the crate.
