Sample pricing is around $0.45 per meter for the 2.5mm², mid-volume orders of 500-1000 meters drop to about $0.32, and bulk runs over 10,000 meters can get you closer to $0.22 per meter — we usually have stock on black and red, but custom colors add a week or so to lead time.
Basically, the 90°C continuous rating means it handles the heat from direct sun on rooftop arrays better than standerd PV wire, and the XLPE insulation holds up well against UV exposure for 25+ years. Most buyers go with the 4mm² or 6mm² for typical string inverters, but if you're running high-votage DC at 1500V, the 10mm² is a safer bet for voltage drop.
What it does is give you a single cable that works for both AC 600/1000V and DC 1000/1500V systems, so you're not juggling two different wire types on site. The tinned copper conductor resists corrosion in coastal or indutrial installations where moisture and chemicals eat standard copper alive.
We've been shipping these to commercial solar farms for about three years now, and the failure rate on returns is under 0.5% — mostly from installers kinking the cable during pull-through, not from the cable itself. Certifications include ISO, CE, and RoHS, but if you need a specific TUV mark, just confirm that when you order because not every batch carries it.
One thing that's not obvious from the spec sheet is the bending radius at 4× cable diameter is tighter than most competitors who spec 6×, which makes a real difference when you're routing through crowded combiner boxes or tight conduit runs. It's not suited for direct burial in rocky soil without a conduit though — the mechancial strength is good, but sharp rocks can nick jacket over time.
Yes, we can mix sizes in a single order. Just let us know the quantity for each size, and we'll bundle them accordingly. The MOQ per size is typically 1000 meters, but that's flexible depending on the total order volume.
Custom colors usually add about 7-10 business days to the standard lead time. Standard black and red are ready to ship within 15-20 days from order confirmation, so custom colors run around 22-30 days. We'll confirm exact timing when you place the order.
Absolutely — we can supply test reports from our lab showing UV exposure and thermal aging results that confirm the 25+ year service life. We also include ISO and CE certificates with every shipment. Just request the reports in your order notes.
Yes, the 4× diameter bending radius applies to both single and multiple core cables. That said, for multiple core bundles, we recommend slightly larger radius during installation to avoid stress on the cores. The spec is tested and holds for all configurations we offer.
Sure, we can do custom lengths on reels — just specify the length per reel and the total quantity. Standard packaging is 100m or 200m rolls, but we can adjust to your needs. For custom reels, the lead time might extend by a few days for re-spooling.
