Sample runs sit around $45-$85 per unit depending on connector count and wire gauge, mid-volume orders of 500 pieces drop to about $12 each, and bulk buys of 10,000+ hit $4.50 or less — a buyer's custoemr will plug these into a car's door control module and expect 100k actuations without a single pin losing contact.
We've run these through 72-hour humidity cycling at 85% RH and 85°C on an oven test jig, and the PVC pipe bandaging holds up better than heat-shrink alternatives for tight-radius routing inside dash panels (usually what appliance folks want for washing machine lid switches).
Actually, the molex 2.54mm pitch IDC sockets crimp consistently at 12-14 lbs pull force when you use our die set — just be aware the low voltage signal harnesses won't handle 48V systems like some EV battery interconnects require, and we don't recommend them for RF assemblies because the unshielded round construction picks up noise.
You'll see roughly 0.05 ohms contact resisance on DC/DC interface types after 100 cycles, and we typically stock the JST XH series with 28 AWG tinned copper in lengths of 150mm, 300mm, or you can specify custom any number.
About 80% of our automotive orders ask for ISO 9001-compliant COAs with each batch; the CCC mark covers Chinese domestic vehicle registrations while teh RoHS data sheets list phthalates below 1000 ppm on that PVC sleeving.
Sourcing for a motorcycle ignition harness might mean dielectric testing at 500V between wires for 60 seconds, and our standard PP bag packaging works fine for most, but check lead time if you need anti-static bags for sensor modules — that adds 8 days or so to the 3-week baseline.
We typically start at 1,000 units for standard configurations, but we can go lower for first-time orders or samples — just tell us your volume and we'll work with you.
Lead time runs 3-4 weeks for custom designs after you approve the sample. Standard configurations ship in 2-3 weeks, depending on order size.
Yes, we include all three — RoHS, ISO9001, and CCC — with every order. You'll get digital copies upfront and physical ones with the goods.
Absolutely, it's solid copper wire throughout. No CCA here — we use pure copper for reliable low-voltage signal transmission in automotive and appliance setups.
Each harness goes into a PP bag, then we bundle them in cartons. For larger orders, we can vacuum-seal or use anti-static bags on request.
