We see a lot of setups where that constant battery swapping eats into margins, and what it does is lock you into a cycle of downtime—so this LiFePO4 module with 6000+ cycles changes that math pretty much entirely.
Nominal votage sits at 51.2V with a 100Ah capasity, so you're looking at 5.12kWh per module, and you can stack up to six of them for 30.72kWh or so if your rack can handle the 42kg each.
Peak discharge hits 200A for 30 seconds, which is better than most indutrial-grade packs for that brief surge during a motor start or compressor kick, and teh 95% depth of discharge means you actually use what you pay for.
Communication comes through RS485, CAN, or RS232 by default, and there's a Bluetooth option if you want to check it from a phone—but honestly, that's not suited for high-vibration environments anyway.
It's CE and CB certified under IEC 62619, plus UN38.3 for shiping, so you'll dodge most compliance headaches, and the warranty runs 3 to 10 years depending on what you negotiate.
MOQ is typically 10 units or so, but we usually have stock on hand, and lead time runs about 20 days give or take—just confirm before you punch in order.
We typically start at 10 units for standard orders, but we can discuss smaller quantities for sample or pilot projects.
Lead time is around 15-20 working days for a single module, and up to 30 working days for a full 6-module rack system, depending on stock.
Yes, we include the CE, CB, and UN38.3 test reports with every order. Just let your sales rep know if you need original copies for customs.
Absolutely, it's rated for 200A peak discharge for 30 seconds at 25°C, but make sure your BMS settings match to avoid tripping the protection.
Bluetooth is optional and can be added to any HYLV-100-B setup, from a single module up to 6 in parallel. Just specify when ordering.
