Frame sizes run form 60mm up to 104mm, and output power is custom between 3W and 200W — that's a pretty wide band, so you'll find something that fits. Most buyers go with the 90mm or 104mm for machine tool applications because they handle torque better than the smaller ones.
Shaft options are 8mm, 10mm, 12mm, or 15mm diameter, and you can pick round, D-cut, or key-way depending on how you're coupling it. The gear ratio range is 3G to 300G, which is flexible enough for most feed or spindle drives. it come in induction, reversible, torque, and speed control motor types — the torque type is better than the induction one if you need constant tension or positioning. Votage choices include single-phase 100-120V or 200-240V, plus three-phase up to 440-480V, so it covers both domestic and export setups. Also, the starting mode is variable frequency, which means you'll need a VFD unless you're running it straight off a line.
Gearbox options are parallel shaft, right angle, or L type — the parallel shaft is what we usually stock for machine tools, but the right angle saves space if your layout is tight. Casing protection is standdard, not IP-rated, so it's fine for dry indoor environments but not for washdown or dusty shops. One thing you might not think to ask: the 60W and above units have cooling fans built in, but below that they don't — so check your thermal load if you're pushing a 40W motor hard.
Certifications are CCC, CE, ISO9001, and CQC, which covers most regulatory requirement for industrial gear. We've ordered these before for a similar setup, and the lead time was about 20 days or so — confirm if you need it faster. The 4-pole design keeps the speed around 1450 rpm at 50Hz, give or take, which is standard for most machine tool applicaion anyway.
Basically, it's not suited for high-speed spindles or continuous reversing under full load — the gearbox can handle intermittent duty but not constant shock loading. Anyway, we usually have stock on the 60mm and 70mm frames, but the 104mm might need a few weeks (check lead time).
For custom specs like a 200W motor with a 90mm frame, our MOQ is typically 100 units. If you need less, we can sometimes work it out, but pricing will be higher.
Yes, all our motors, including the 104mm frame size, come with CCC, CE, ISO9001, and CQC certifications. We can provide copies of the certificates with your order.
For a custom batch with a 300G gear ratio and D-cut shaft, lead time is about 25-30 working days from order confirmation. Rush orders can be expedited if you let us know upfront.
Absolutely, we can pair a speed control motor with 440-480V three-phase input and a parallel shaft gearbox. Just specify the gear ratio and shaft type when ordering.
Store it in a dry, clean area with standard protection, away from dust and moisture. Keep it in its original packaging and avoid temperatures above 40°C or below -10°C to prevent damage.
