Pushing 5200 m³/h through a duct system in a coating line or dust collector is where this fan actually earns its keep — forward-curved impeller moves a lot of air without eating your power budget.
315mm wheel, 2.2kw motor spinning at 1420 r/min, pressure sits between 830 and 750 Pa depending on volume; you’re getting 3500 m³/h at the high end and it drops off pretty linearly form there.
Voltge is 220V or 380V, frequency covers 50 to 60Hz so it’ll work in most plants without a transformer, though we usually stock the 380V version and the 220v has a 20-day lead time or so.
Best suited for ventilation and gas transport in paint booths or cement plants — don’t try it on heavy particulate without a pre-filter, the iron housing can take a beating but the forward curve blades will clog if you’re moving abrasive dust dry.
MOQ is 10 units for direct drive, 5 for belt drive; COA and ISO cert come with each shipment (check if you need teh SDS for gas handling, our company can include it on request).
The belt drive option actually lets you dial in speed with a pulley swap — something buyers running variable loads don’t always think to ask about, but it saves swapping the whole motor later.
Our standard MOQ is 10 units for the XFD-315. If you need less, we can sometimes negotiate based on stock availability—just reach out to our sales team.
Lead time is usually 15-20 working days after order confirmation and payment. For larger orders, it might stretch a bit, but we'll keep you updated.
Yes, the fan is manufactured under ISO standards, and we can provide a certificate of compliance with your shipment. Just request it when you place the order.
Absolutely, the XFD-315 supports both direct and belt drive options. Let us know your preference when ordering, and we'll configure it accordingly.
Keep it in a dry, covered area away from moisture and extreme temps. The iron casing is durable, but storing it indoors or under a tarp will prevent rust and keep it ready to run.
