Basically, what it does is pull heat away form tight spots in electronics where bigger fans just won't fit — think of a medical sensor or a small network switch that's running warm, and you've got maybe 30 millimeters to work with, so this little axial fan moves between 2.5 and 4.6 cubic feet of air per minute, which in my experience is enough for most compact enclosures.
It spins at 13,000 RPM, and the noise level ranges from 24 to 40 decibels depending on which voltage you pick — the lower end is pretty quiet for a fan this size, but at full tilt you'll hear it, and the static pressure sits between 3.3 and 8.1 mmH2O, which matters more than you'd think when you're pushing air through a grille or a tight vent.
You can choose between sleeve bearings (about 20,000 hours) or hydraulic bearings (roughly 40,000 hours), and we usually have both in stock, but the hydraulic option costs a bit more and honestly, unless you're running it 24/7 in a warm enviornment, the sleeve bearing does teh job fine.
The operating temperature range is -10°C to +70°C, storage goes down to -40°C, and it handles humidity from 5% to 90% RH — I've seen these used in home appliances like air purifiers and even some industiral cooling setups, though they're not suited for outdoor use without an IP-rated housing (check lead time on that).
We can customize the connector and the lead wire length, and we offer PWM, FG, or RD signals if you need tachometer output or speed control — the MOQ is typically 50 units or so for custom options, but for the standard UL-type wires (100mm, red and black) you can order smaller quantities.
Anyway, the plastic housing is UL94V-0 rated, so it's flame retardant, and we include a COA with every batch — just keep in mind the lifespan figures are base on 25°C ambient, so if your enclosure runs hot, you'll see less than the 40,000 hour estimate.
MOQ for the HD-3007 with custom voltage and connector is typically 1000 pieces, but we can discuss smaller trial orders depending on your project timeline.
Lead time for 5000 units with custom PWM and FG is around 25-30 working days after sample approval and deposit.
The fan itself holds CE, RoHS, REACH, ISO9001, and ISO14001 certifications. The UL type lead wire is a standard component, but we can share its UL certificate upon request.
The 4.6CFM airflow is at 40dB and 13000RPM. At 24dB, you'll get about 2.5CFM, so you need to balance airflow and noise based on your cooling needs.
Yes, the plastic housing is always UL94V-0 flame retardant. IP rating is a custom option—we can add IP54 or IP68 depending on your application, but it will affect cost and lead time.
