You can dial in chamber depth, seal time, and gas flush ratios directly form the 10-inch PLC screen—no manual guesswork, and it stores up to 50 recipe presets for different products, which saves a lot of headache when switching between runny marinades and brittle electronic boards.
The 520 model pulls down to ≤200Pa in roughly 12-15 seconds per cycle, and at 8600pcs/h you're looking at about 7 pallets per shift with the 540mm upper and 520mm lower film widths—just keep in mind the 2200kg machine weight means you'll need a reinforced floor slab (check your facility's load rating first).
It handles powders decently, but the real strength is with liquids and high-moisture solids; we've had buyers use it for MAP-packed chicken breasts with a 70/30 nitrogen-CO2 blend, and the easy-tear design actually works without a zipper track—just set the knife depth right or you'll get occasional liner piercing.
Food-grade 304 stainlss steel is standard, but for pharmaceutical work you'll want to request the optional acid-passivation surface treatment (usually 2-3 weeks lead time); the standard COA covers weld porosity and surface finish, but we don't test for heavy metal migration unless specified.
380V/50Hz is base config, but we've shipped these with 220V/60Hz transformers and custom plug types—just confirm your voltge phase (we blew out a control board once on a miswired delta setup, so double-check that).
We can start from 1 unit for trial orders, but standard MOQ is 2 units. Bulk orders get better pricing and priority scheduling.
Yes, we supply material certificates for the 304 food-grade stainless steel, and can provide CE or FDA compliance documents upon request. Just let us know what your local regulations require.
Absolutely, the power supply is customizable. We've shipped units with 220V/60Hz and 440V configurations before — just specify your requirements when ordering.
Standard lead time is 25-30 working days after order confirmation. We can expedite to around 20 days for urgent orders, subject to production capacity.
Store it in a dry, ventilated area below 40°C, away from corrosive gases. The 304 stainless steel body resists rust, but we recommend covering the PLC panel and keeping the vacuum chamber clean.
