Actually hits the 680 Nm mark pretty consistently across multiple test runs we've done, and that twin hammer mechanism handles seized bolts better than the pin-style clutch units. The adjustable regulator lets you dial it back to around 200 Nm for lighter work—most guys go with mid-range setting for wheel nuts.
Free speed is 7000 rpm at 90 psi, though it's usually around 6400-6600 if your compressor line is undersized, which it often is. 1/2 inch drive is the standard for automotive work, but it's not great for precision assembly on engine internals—you'd want a torque-limited tool for that. The two-piece serviceable housing is a nice touch; you can get the hammer case off without pulling the whole thing apart.
We've shipped these to a few heavy equipement shops who mainly use them on suspension work, and the adjustable regulator has been the main selling point for them (they run it at about 450 Nm for control). The hand-press start is pretty much instant response, no trigger lag like some cheaper units. One detail you might not think to ask about is the exhaust port—it directs air away from the handle, which keeps your hand from freezing up on cold mornings.
Color box packaing comes with the standard 10 units per carton, so the MOQ is typically one carton unless we arrange split shipments. The carton dimensions are 38 by 24 by 23 cm, and net weight per unit is about 1.4 kg give or take—gross weight for the full carton runs 15 kg. We usually have stock, but confirm lead time if you need more than 50 units or so.
Better than most budget impact wrenches for sustained torque delivrey, though it's not designed for continuous production line use—the twin hammer mechanism does generate more vibration than a clutch unit over long periods. The adjustable regulator is actually calibrated reasonably well from the factory, but we always recommend checking it against a torque stick for critical fasteners.
The standard MOQ is 10 units, as each carton holds exactly 10 wrenches. We can discuss smaller trial orders if you're just testing the market.
For an order of 200 units, lead time is usually around 20-25 working days after confirmation and deposit. This can vary slightly depending on our current production schedule.
Yes, we can supply a CE certificate and a full test report for the twin hammer mechanism. Let us know if you need specific documentation for your market.
The regulator lets you dial in the torque from low to high, but it's a continuous adjustment without a locking click. It stays in place during use, so you can set it and forget it until you need a change.
Each wrench comes in a color box, and we pack 10 boxes per carton. The carton measures 38x24x23 cm, with a gross weight of 15 kg per carton for shipping.
