100 meters is our MOQ on the TRVV series, and we can ship within 7-15 days on standard orders — wooden spool or coil, your call on black, gray, or orange sheathing.
Basically, these are built for continuous flex applictions where you need that 8-million-cycle minimum, so we use high-purity copper conductors and a PVC/nitrile blend outer jacket that handles oil, water (IP67 equivalent), and UV exposure without cracking.
temperture range is -40°C to +105°C, and the flame rating is UL VW-1/FT1 — it's better than standard PVC for this kind of stress, and we've got CE, RoHS, and ISO9001 if your compliance team asks.
0.15mm² is the standerd conductor size, but we can do 2-core up to 30-core depending on your signal needs; just don't expect this to work well for high-votage power transmission — it's a signal and control cable, not a main feeder.
One thing you might not think to ask: teh 8 million cycles is tested at a specific bend radius, so if you're running tighter than that, you'll see reduced life — we usually have stock, but confirm lead time if you need a custom color or core count.
We've handled these for years in pick-and-place robots and CNC drag chains, and the PVC/nitrile jacket actually holds up better than polyurethane in continuous oil mist environments — most buyers go with orange for visibility on the floor.
We recommend a bend radius of at least 7.5 times the cable diameter for standard applications. For the full 8 million cycles, stick to that radius—tighter bends will reduce lifespan.
Yes, we can share a bending life test report upon request. It's part of our ISO9001 quality docs, and we run internal tests on every batch to confirm the cycle count.
Sure, we can match custom colors—just send us a RAL code or sample. Minimum order for custom colors is still 100 meters, and lead time might add a couple days.
Absolutely, the PVC/Nitrile blend sheath has built-in UV resistance, so it holds up fine outdoors. Just keep the temperature within -40°C to +105°C, and you're good.
We ship on wooden spools for 100 meters and up, or coils for smaller lengths. Unfortunately, we can't split a 100-meter spool—that's the MOQ—but we can cut to your exact length per order.
