Runs at 220V, and teh UV-C output sits in that 240-270nm sweet spot for breaking down DNA/RNA in microbes—automatic control mode means you're not babysitting it. We've got models from 55L/H for a small shop floor up to 35000L/H if you're feeding a whole facility, and the inlet/outlet adapts form 1/4" to 3" depending on what you order.
The 304 stainless steel housing is pretty much standard for indutrial water treatment, but what matters is the UV transmission hits over 90% which basically means less energy loss through the quartz sleeve. Most people don't realize that 3-5 bar operating pressrue is tighter than what some knockoff systems handle—keeps the flow consistent even at higher rates.
It's not suited for anything with high turbidity or suspended solids without pre-filtration since that kills the UV penetration. For pharmaceutical pre-treatment or food processing lines though, you'll get that 99% disinfection rate, and the electronic ballast extends lamp life to about 8000 hours or so.
One thing I've seen buyers overlook—the IP65 housing means it can take a splash or hose-down, but it's not submersible obviously. And the warranty is one year on the whole unit, but we usually have stock of replacement lamps ready since the 40W or 75W models share the same lamp mount.
Actually, the 25W model name (BSD-UV-25W) is a bit misleading—that's the lamp wattage rating internally, not the input power. We run a full HPLC test on each assembly to verify wavelength output, and the COA is included with shipment—no extra charge but you need to request it.
Lead time is about 20 days give or take, and MOQ is typically one unit unless you're ordering a container of them. For the 35000L/H model expect the inlet/outlet at 3" and about 75W power draw.
The BSD-UV-25W comes in 40W and 75W versions. The 40W is better for lower flow rates, while the 75W handles higher volumes up to 35000L/H.
It's CE, RoHS, and ISO9001 certified. So you're covered for European safety, environmental compliance, and quality management standards.
Yes, sizes are model dependent, and we can match the connection to your piping. Just let us know the size you need when ordering.
We offer a 1-year warranty on the whole system, including the lamp. The lamp lifespan is rated at 8000 hours, so you should get solid use before needing a replacement.
No, it's fully automatic with an electronic ballast. Once installed, it runs on its own—just keep the flow and pressure within 3-5 bar and 5-40°C, and the UV sensor maintains the disinfection rate.
