15.6 Inch TFT LCD Touch Screen Hospital Ventilator with CE FDA ISO13485 Certification

The 15.6 inch colorful TFT LCD touch screen ICU ventilator is a fully electronic controlled medical device designed for hospital surgical equipment. This advanced ventilator system is suitable for neonatal, pediatric and adult patients with a tidal volume range of 5-2000ml.

Featuring a high-resolution SVGA display, all parameters and alarm limits can be easily adjusted by sliding the touch screen interface. The ventilator utilizes blower (turbine drive) technology and offers complete ventilation modes including PC-CMV, Spn-CPAP, PC-SIMV, PC-AMV, PC-MMV, VC-ACV, VC-SIMV, VC-CMV, PC-APRV, and PC-Dual PAP.

The device includes special functions such as manual breath, O2 therapy, standby, screen-lock, inspiratory hold, expiratory hold, sigh, ATC, PCVR, PPS, Compliance, Nebulizer, and O2 suction. Multiple interface options are available including USB, NET, RS232, VGA, and Nurse Call. Optional features include ETCO2 and SPO2 monitoring capabilities.

With its active matrix color TFT LCD display offering VGA resolution (1366 x 768), medical professionals can clearly monitor patient data. The ventilator supports various patient types (adult/pediatric/neonate) with adjustable height settings. Real-time waveforms display Paw, Flow, Volume, EtCO2, and SPO2 data, while loops show P-V, V-Flow, and Flow-P relationships.

The comprehensive monitoring system provides trends at various intervals (5s, 1min, 10min, 30min, 60min) for better patient assessment. The device offers precise control with tidal volume ranging from 10 to 2000mL, PEEP/CPAP from 0 to 40 cmH2O, and oxygen concentration from 21 to 100%.

Advanced features include adjustable inspiratory time (0.2 to 5s), pressure trigger (-0.5 to -20cmH2O), flow trigger (0.2 to 15L/min), pressure control (5 to 90 cmH2O), pressure support (0 to 90 cmH2O), and pressure ramp (1% to 50% of inspiratory time). The expiratory trigger sensitivity can be set from 5% to 90% of inspiratory peak flow.

This medical ventilator meets international standards with CE, FDA, and ISO13485 certifications, ensuring quality and reliability for critical care applications. The device operates on 100 to 120V AC (±10%, 50/60Hz) or 24VDC (±10%) power input.
