Multi-Angle Mining Drill Rig with 3000N.M Torque and 45° Frame Adjustment

The GL120YG-A High Air Pressure Drill Rig is a powerful mining equipment designed for efficient blasthole drilling operations. This robust machine offers exceptional performance in surface mining, stone works projects, conservancy and hydropower applications, road construction, and solar panel installation projects.

This drill rig features a hydraulic system powered by either diesel engine or electric motor, providing reliable power for various functions including hydraulic motor walking, rotation, pushing and lifting operations. The equipment demonstrates remarkable gradeability and offers floating adjustable parallel mechanism for stable operation on uneven terrain.

With its multi-angle drilling capability, the GL120YG-A can handle challenging working conditions with large gradients and frequent movement requirements. The drill rig achieves impressive drilling speeds of 20-35 meters per hour in rock with rigidity f=6-18, making it significantly more efficient than traditional pneumatic drills while saving over 30% energy consumption.

The machine's frame can swing left 50° and right 35°, with stick swing capability of 45° in both directions, allowing for flexible positioning and precise drilling operations. The angle of frame adjustment ranges from up 45° to down 60°, accommodating various drilling requirements in different working environments.
