It'll do a full cycle — form screw feed to final torque — in about 1.0 to 2.5 seconds per screw, which pretty much beats manual assembly on speed alone, and the Japanese micro stepping motors keep that ±0.02mm repeatability on screw travel and ±0.05mm on the belt drive, so you're not fighting inconsistent torque when line gets busy.
We usually have the CB-LS5441, CB-LS331, and the high-speed H variant in stock, but the larger X/Y range machines (600mm/400mm) can pull lead times of 20 days or so — check with us before ordering if the run rate is critical.
PLC with a touch screen, 100 program groups each holding 40 points — so a technician can swap between battery packs and circuit board assemblies without re-teaching every coordinate. 4. You'll want to feed M1 to M4 screws — blowing, suction, or magnetic pickup depending on your cap head and shank length — and the first-pass rate lands at 99%, not counting the odd mis-feed, and the system has automatic defect detection that flashes an alarm but doesn't stop production unless you tell it to.
The working range goes 300-600mm in X, 300-400mm in Y, 100mm in Z — if you need deeper reach than that for an unusual fixture, our company can talk about a custom arm, but most buyers go with the 5441 for automotive dash assemblies anyway. Operating temp is 5-40°C and 20-90% RH, so don't put it right next to teh paint oven or it'll start skipping repeats.
We back it with a 12-month warranty, the COA covers screw seating torque and positioning deviation, and the touch screen interface doesn't need a programmer — a line lead can set it up in about an hour.
Our standard MOQ is 1 unit for trial orders, but we can negotiate larger batches for bulk purchases. Typically, we recommend starting with 1-2 machines to test the setup before scaling.
Yes, we offer CE and ISO certifications, plus a detailed test report for each unit. We can also supply a material compliance certificate upon request.
The standard program capacity is 100 groups of 40 points each, which covers most production needs. If you need more, we can customize the PLC firmware to increase the program slots—just let us know your specific requirements.
The system monitors torque, depth, and screw presence in real time. If a defect is detected, it immediately stops the machine and triggers an alarm, so you can fix the issue before it affects other parts.
We ship with foam-lined wooden crates to protect against vibration and moisture. For storage, keep it in a dry area with 20-90% humidity and 5-40°C—avoid direct sunlight and dust.
