That 160 mm²/min speed is what most operators actually care about, and we've seen buyers push it even higher with the right settings—though you'll trade some surface finish for that.
It's a 1400 kg machine, so you'll need a proper floor for it, and the 220V/380V power requrement means checking your shop's setup first. We usually have stock on the standdard model, but the Z-axis travel of 300 mm isn't enough for tall parts, so if you're over 250 mm or so, this isn't the right fit. accuracy spec is ≤0.01 mm, which is pretty much what you expect form a mid-range wire EDM, and teh surfce roughness hits Ra1.2 μm without much tweaking. Most buyers go with the 10mg oil or dielectric flush settings for general work, anyway.
Worktable travel is 320×400 mm, and the table itself is 700×500 mm, so you've got some overhang room for clamps. The max taper is ±6° over 80 mm (check the manual for thicker stock), but for aviation or die work, that's usually fine.
The CE and ISO 9001 certs are standard, and SGS is just a third-party verification we include for peace of mind. Warranty is 2 years, but we've seen the pump system last longer than that if you keep the filters clean.
It's better than most generic Chinese wire EDMs for consistency, but don't expect it to handle super fine finishes below Ra0.8 μm without multiple passes.
The TRS32 pushes a max cutting speed of 160 mm²/min, which is on the higher end for a compact wire EDM — good for getting through jobs faster without sacrificing finish.
Yeah, the accuracy is ≤0.01 mm and surface roughness hits Ra1.2 μm. That's solid for most precision tooling and die work, and the specs are backed by CE and ISO 9001 certs.
Minimum order is usually 1 unit, and lead time runs about 15-20 working days depending on stock. We can speed it up if you're in a pinch.
Absolutely — CE, ISO 9001, and SGS certificates are all included with the machine. We'll send you the copies before shipping.
It supports both 220V and 380V, so you can choose based on your shop's setup. Power draw is 1.5 kW, so it's pretty efficient for a wire EDM.
