Wholesale SC Single-Mode Fiber Optic Adapters and Patch Cords with Telcordia GR-326-CORE Standard

With over two decades of industry experience, our brand is recognized globally, particularly in European and American markets. We specialize in the production of passive components, including patch cords, connectors, adapters, attenuators, splitters, and WDM series. Our products are engineered to meet the rigorous demands of modern communication infrastructure.

Applications for our SC single-mode fiber optic patch cords span across multiple sectors. They are ideal for CATV systems, telecommunication networks, active device termination, metro and local area networks (LANs), data processing networks, test equipment, premise installations, and wide area networks (WANs). These patch cords ensure reliable performance in diverse environments, from industrial settings to commercial installations.

Key features of our SC single-mode fiber optic patch cords include low insertion loss and minimal back reflection loss, which enhance signal integrity. They offer excellent exchangeability, high durability, and superior temperature stability, making them suitable for long-term use. All products adhere to the Telcordia GR-326-CORE standard, ensuring quality and reliability.

Specifications for single-mode variants include a typical insertion loss of ≤0.2dB and a maximum of ≤0.3dB, with a return loss of ≥50 dB for PC and ≥60 dB for APC types. Multimode options feature an insertion loss of ≤0.25dB and a return loss of ≥30 dB. Additional performance metrics include repeatability of ≤0.1, durability with ≤0.2 dB typical change over 1000 matings, interchangeability of ≤0.2dB, and a tensile strength exceeding 70N. The operating temperature range is from -40 to +85°C, ensuring functionality in extreme conditions.

Ordering options are highly customizable. Connector colors include beige, blue, and green, with boot sizes available in 0.9mm, 2.0mm, and 3.0mm. Boot colors vary, such as beige, black, and blue, to match different fiber types including 9/125μm for single-mode and 50/125μm or 62.5/125μm for multimode. Cable configurations range from simplex and duplex to fan-out options with 4, 6, 8, 12, or 24 fibers. Applications cover PC and APC types, with lengths tailored to customer requirements.
