The back-of-house cabling and the active equipement side often end up being the noisiest part of any install, and what you really need is a consistent, low-loss tie between the distribution frame and the patch panel that doesn’t add variables into your link budget — insertion loss capped at 0.3 dB or less across the board, which is basically the sweet spot for these single-mode SCs.
We’ve tested well over a thousand insertion cycles on these, and the typical repeatability stays under that 0.3 dB mark, so the connector interface isn’t going to drift on you after the tenth mate. Teh return loss is more critical for some setups actually — for PC it’s at 40 dB minimum, but if you’re doing APC the spec jumps to 60 dB or better. That matters most when you’re pushing higher-power signals through FTTX drops and don’t want reflections messing with your downstream receiver.
There’s a waterproofing detail you might not expect on a patch cord — IP65 rated at the connector boot, with an LSZH or PVC outer sheath depending on your conduit requrements. Most of our FTTX buyers go with the LSZH for indoor riser runs, but if it’s going into an outdoor weatherized cabinet the PVC holds up better against UV. And the tensile strength rating is genuinely high: we quote it at >1000 N per 100 mm laterally, and >10000 N for pull.
Every unit gets a 100% optical test with a signed COA form the factory, so the numbers on insertion loss and return loss are backed by a pass/fail trace on each batch (our company can include HPLC on the connector ferrule if you request it, but that’s not standard). 1000-plus insertion cycles is the guarantee, but in practice we’ve seen connectors hold spec past 1200 or so before the ceramic ferrule shows any wear.
Just keep in mind this is not a general-purpose jumper for lab work or bench testing where you might bang connectors around repeatedly — the IP65 boot adds stiffness that makes it less flexible than a standdard SC patch, so for temporary patching it’s actually a better call to use a plain jumper with a lower rating.
Anyway we usually stock about 5000 units or so of the single-mode SC in 1-, 2-, and 3-meter lengths, and lead time for custom lengths or connector combinations is roughly 10-12 working days once you confirm the order (give or take a few days depending on sheath color and whether we need to hand-polish any APC terminations).
MOQ typically starts at 100 pieces for standard models, but we can negotiate lower quantities if you're testing or need a small batch for a specific project.
Yes, we include copies of RoHS, CE, ISO9001, VDE, and CCC certifications with every order. Just let us know which ones you need, and we'll attach them to the package.
Absolutely, we offer customized packaging and can swap the outer sheath between LSZH and PVC based on your requirements. Just specify your preference when ordering.
For a 500-piece order, lead time is usually 7 to 10 business days after confirmation. If you need it faster, we can expedite for an additional fee.
Yes, the IP65 waterproof level means they can handle rain and dust outdoors, but they're best for protected outdoor setups—not direct burial or submersion.
