The UL94V-0 rating on these isn't just compliance paperwork — it means the housing won't feed a fire if something goes wrong, which is a big deal for automotive and power appliction in the EU where flammability standard are strict.
We see a lot of customers run these at 85 Ohms for video signals, and the brass contacts with gold plating handle repeated mating cycles without corrosion issues. Basically, if you're bulk ordering for a production run, the nylon housing keeps teh 0.5mm pitch aligned even after 200 or so cycles.
Import into the US is straightforward since we include RoHS and MSDS docs automatically, and ISO 9001 is standerd for our line — just request a COA if you need it for your audit.
One thing we've noticed is that the 2.50mm mated height variant is easier to work with in tight PCB layouts, though the 9.60mm version is better for applictions where you need clearance. We don't recommend these for high-frequency transmissions above 100MHz or so, as the 85-100 Ohm impedance range is designed for low-frequency signals.
4-24 circuit options mean you can match almost any FPC ribbon cable, and we usually have 50,000 units or so in stock for the 10mg sizes — actually, the 10-circuit version is what 30% of buyers order, give or take.
Processing temperture at 230°C for 10 seconds is tight but doable with standard reflow, just confirm your solder paste profile first. We supply to UK assemblers regularly and ship with full customs paperwork.
That impedance range means these connectors are designed for controlled impedance signal paths, typically used in high-frequency or differential signal applications like DVI or LVDS. It helps maintain signal integrity over the connection.
Yes, we provide MSDS, ISO 9001, and RoHS certification documents with every bulk shipment. Just let us know if you need a specific format or additional documentation.
MOQ for these connectors is typically 1,000 pieces per circuit count, but we can be flexible for first-time orders or smaller test batches. Contact us with your target quantity and we'll work something out.
Lead time is usually 15-20 working days for standard orders, depending on the circuit size and plating choice. If you need faster delivery, we can check our stock or expedite the production schedule.
Store them in a cool, dry place away from direct sunlight and moisture, ideally between 15°C and 35°C. Keep them in their original anti-static packaging to prevent dust or damage.
