For OEM builds where you're wiring control boxes or small appliances, this flat cable saves space and routes cleaner than round stuff — we ship it wound on 100-meter or 305-meter rolls, and MOQ is usually one roll per core count.
Basically it's a stranded copper conductor (tinned or bare, your call) wrapped in PVC insulation and a PVC sheath, good for 300V at 80°C continuous. It passes the UL VW-1 flame test, so it's fine for internal runs where fire spread matters. You're looking at 2 to 5 cores in a flat profile, and we've got custom colors if you need to match harnesses or just want something that's not black.
The flame test isn't just paperwork — we've had these cables handle brief overloads without catching, which matters more than the spec sheet suggests. One thing: it's designed for internal wiring only, not for continuous flexing or outdoor exposure, so don't try to use it as a pendant cable or extension cord.
When you order, you get a roll with a COA form our in-house lab stating conductor resistnce and insulation thickness (typically ±0.05mm on the wall). Standdard colors are black, white, and red for sheath, but if you need a specific Pantone, give us the number and lead time goes to about 15 working days or so — we do free sample rolls for conventional specs to check fit.
Also, the 305-meter roll is better value per meter than teh 100-meter (roughly 15% cheaper per unit), but if you're prototyping or need short runs, the smaller roll is easier to handle. We usually have stock on 2-core and 3-core black in the 100-meter format, but confirm lead time for 4-core or custom colors.
We don't have a strict MOQ for this cable. For standard colors and 2–5 cores, we can accommodate small trial orders. Custom specs or colors may require a larger quantity, but we'll work with you.
Yes, we include a certificate of conformity for UL, VDE, and RoHS with every batch. ISO9001 and CCC documents are also available on request.
Absolutely. Conventional samples are free, you just cover the shipping. We can send a 1-meter piece of your chosen core count and color.
We offer both options — tinned or bare stranded copper. Just specify which you need when you inquire, and we'll confirm pricing.
It's supplied in 100-meter or 305-meter rolls. Each roll is individually wrapped and labeled. If you need custom packaging for retail or specific labeling, we can arrange that too.
