So we're ordering the copper-based wires with PVC insulation, rated 300V/500V up to 450V/750V depending on the variant, and the temperature rating is 70°C which is standard for most internal wiring applicaion—flame test compliance is IEC 60332, and we've got ISO9001 and RoHS certs already on file, plus CCC and cUL for export flexibility, though IATF 16949 is only relevant if automotive buyers ask for it later.
Basically, the conductor options are tinned or bare copper, stranded or solid, and sizes range form 0.08mm² up to 35mm², with single core to 24 cores in round or flat configurations, so it covers pretty much everything from appliance leads to power distribution panels, but it's not suited for high-temperature environments above 70°C or outdoor direct burial without conduit.
Most buyers we've dealt with go with the RVV or BVR types for flexible routing in control cabinets, and the RVVP shielded version is actually better than standard PVC for signal integrity in noisy environments—just keep in mind the 0.08mm² minimum might be too small for heavy current loads, usually 1.5mm² or 2.5mm² is what you'll see for lighting circuits.
Lead time is roughly 3 weeks for standard sizes like 1.0mm² to 6.0mm² in single core, but if you need 24-core configurations or oddball sizes like 0.5mm² or 35mm², expect 20 days or so plus shipping—check MOQ on those because we usually have stock on common gauges, but confirm lead time for anything outside the 0.75mm² to 10mm² range.
Also, the packaging is typically on 100-meter or 500-meter reels, and the COA includes HPLC purity data for the insulation materail, though for the copper conductor they just give you the conductivity test results, not a full breakdown of trace elements—most buyers don't ask for that anyway, but if you need it for a specific spec, request it at order time.
Yes, we can customize the PVC insulation color and add striping based on your request. Just let us know the specific color code or pattern you need.
For multi-core custom cables like RVVP with 24 cores, our MOQ is typically 500 meters. Smaller quantities may be possible for standard types, but custom builds need that minimum to set up production.
Absolutely. We include the relevant certificates like RoHS, CCC, and ISO9001 with every batch. If you need a specific test report for IEC 60332 flame test, just request it when you place the order.
For that size and material, lead time is usually around 15 to 20 working days after order confirmation. Stock items might ship faster, but custom tinned copper takes a bit longer to source and process.
Yes, we offer flat cables in configurations like RVB. For 4 cores, we can produce flat shapes as long as the total cross-section fits within our size range. Just confirm the conductor size and we can make it work.
