We usually stock this in standard coil lengths, but custom sizing means lead times can stretch to 20 days or so depending on teh batch—don't expect overnight delivrey.
What it does is handle the heat and cold extremes better than most PVC wires, with that -60°C to +180°C range actually holding up in real-world oven and freezer applictions we've seen.
The tinned copper stranding gives it a bit more flexibility than solid core, so it's easier to route in tight headlamp housings or behind appliance panels without cracking.
2000V testing voltge is standard here, so you're covered for the 450V/750V nominal rating, but it's not meant for high-frequency signal work—stick to shielded cable for that.
Avaliable in 0.50mm² up to 2.50mm² conductor sizes, and we can do custom color runs if you need more than the usual black, red, or green/yellow (minimum order is 100m per color).
One thing a lot of buyers don't think to ask: the ±0.10mm OD tolerance is tighter than some generic silicone wire, which matters if you're feeding it through precision grommets or connectors.
For custom sizes like the 0.50mm², our MOQ is typically 1000 meters per specification. That can be spread across multiple colors if needed, but we'll confirm once you share your exact requirements.
Standard lead time for custom colors is about 15-20 working days after order confirmation, since we need to schedule production. For stock colors like black or red, we can usually ship within 5-7 days.
Yes, we can share our ISO9001, UL, and RoHS certificates on request. Just let us know which docs you need, and we'll email them over with your quotation.
For 305m coils, we use spools wrapped in protective plastic and packed in sturdy cartons. If you need special packaging like export-grade wooden reels, we can arrange that at a small extra cost.
Yes, the ±0.10mm tolerance applies across the full conductor size range. Our QC checks every batch to ensure it stays within that spec, so you can count on consistent dimensions.
