CE FDA ISO13485 Certified MS-M540 Anesthesia Machine for Adult Patients

The MS-M540 Anesthesia Machine is a high-performance medical device designed for surgical applications in hospital settings. This advanced anesthesia system combines pneumatic and electric control mechanisms to deliver precise ventilation support for adult patients.

Featuring an 8.4" TFT display, the MS-M540 provides clear visualization of all critical parameters including tidal volume, respiratory rate, and airway pressure. The machine supports multiple ventilation modes including IPPV, SIPPV, VCV, IMV, and SIMV, making it adaptable to various clinical requirements.

The gas system includes flowmeters for O2, N2O, and Air with adjustable ranges from 0.1-10L/min. The machine is compatible with Selectatec vaporizers and features a 1.5L absorber volume. Comprehensive monitoring capabilities include minute volume, tidal volume, breathing frequency, peak pressure, PEEP, and airway resistance measurements.

Safety features include audible and visual alarms for tidal volume, airway pressure, oxygen concentration, asphyxia, power failure, and oxygen failure situations. The machine operates on standard electrical specifications (110V~240V, 50/60Hz) and includes a 3-hour backup power supply.
