Ran it at 320 pieces per minute on our last factory trial with a >97% qualification rate on the first pass, and that's with the high-density ultra-thin fluff core forming system actually running—it's not just a spec sheet number, PLC with touch screen gives you real-time viscosity or density adjustments on the fly if you're switching between T-type and standard waist designs.
One-button size change means you won't lose half a shift when you swap form a circle waist to a brief-style diaper, but the real trick is the servo-driven active unwinding and auto-splicing—without it, matrial handling jams at high speeds (we learned that the hard way on earlier models), so you'll want to have your roll stock prepped for that 380V 50Hz three-phase feed.
Also, the full servo drive system on the CSG-AD350 keeps tension control tighter than most units we see in the field at this price point, but it's not plug-and-play for every glue formulation—if you're using a hot-melt with a melt point above 180°C, the digital tension system needs a calibration tweak, usually takes an hour or so during commissioning.
For storage and test methods, keep your fluff pulp at 20-25°C and <50% RH or the core forming will drift—we've seen qualification rates drop by about 2-3% when humidity spikes, and the CE certification covers electricla safety but not enviromental conditioning, so a dehumidifier in the production bay is a practical addition.
Anyway, the 15-ton machine footprint at 35m long is actually the standard for 180-350 pcs/min output, but what it does is give you one-button changeover without manual die swaps, which saves about 4 man-hours every shift—better than dealing with intermittent splicing failures on older lines.
We usually have stock, but confirm lead time for the 1-year warranty and ISO9001 paperwork—customiaztion on core thickness or unwind shaft length is available, but you'll need to send over your raw material specs (like pulp density or SAP particle distribution) so the PLC can map the servo profiles accurately.
Standard lead time is about 45-60 days after deposit, depending on customization. We'll give you a confirmed schedule once we finalize the specs.
Yes, it handles full size range with one-button operation. A full size change takes under 10 minutes, including adjustment of core forming and tension settings.
We supply CE, ISO9001, and ISO14001 certificates. The CE mark covers EU machinery directive requirements, so it's good for European customs clearance.
MOQ is 1 set. We don't require multiple units. Customization like servo drive tuning or core density adjustment is available on single orders.
It ships in 2-3 containers, depending on options. You'll need about 35m length, 5m width, and 3m height for the line, plus extra space for material storage and operator access.
