WAGO Programmable Logic Controller PFC200 with Ethernet Interface for Industrial Automation

The WAGO PFC200 Programmable Logic Controller is a versatile industrial automation solution designed for demanding control applications. With its powerful Cortex A8 processor running at 1 GHz and real-time Linux operating system, this PLC delivers exceptional performance for complex automation tasks.

This industrial controller supports multiple programming languages per IEC 61131-3 standards, including Instruction List (IL), Ladder Diagram (LD), Function Block Diagram (FBD), Continuous Function Chart (CFC), Structured Text (ST), and Sequential Function Chart (SFC). The programming environment is compatible with CODESYS V3.5 and higher, e!COCKPIT, and WAGO-I/O-PRO V2.3.

The PFC200 features comprehensive communication capabilities including CANopen, Modbus TCP master/slave, Modbus (UDP), EtherNet/IP Adapter (slave), EtherNet/IP Scanner, EtherCAT Master, OPC UA Server/Client, and MQTT. With its Ethernet interface supporting 10/100 Mbit/s transmission rates, this controller easily integrates into modern industrial networks.

For power supply, the PFC200 operates on 24V DC system voltage with a -25% to +30% tolerance range. The controller features three outgoing power jumper contacts with 10A current carrying capacity and 500V isolation between system and field power.

The hardware specifications include 512MB RAM, 4096MB flash memory, and support for SD/SDHC memory cards up to 32GB. The controller can handle up to 250 modules per node, with a maximum of 64 modules without bus extension.

Visualization options include Web-Visu capability, and the controller supports various telecontrol protocols including IEC 60870, IEC 61850, and DNP3 (with additional licenses). The compact DIN rail mount design makes installation simple in control cabinets.
