We've had good results with the SC-J3000+ covering 300MHz up through 6GHz — that's pretty much the full range you'll see on consumer and indutrial drones — and the jamming distance hits 3km or so against a 0.1W radiation source, which is better than most in this class for price point.
You're looking at ≤3 seconds to neutralize a target once it's acquired, and the PTZ sweeps 360° at 60°/s or faster, so it'll track multiple threats in sequence without lagging behind; it basically handles the crowded urban scenarios we've tested it in, but it's not ideal for wide-open rural coverage where you'd want a distributed array instead.
CE and RoHS and ISO are all in place, and the transmit power stays under 50W per band to keep regulatory headaches manageable — though check your local frequency allocations because the full pass-through can overlap with some licensed bands in certain regions (we usually have stock within 15 days or so for customs-cleared units).
The enclosure is IP65 rated, so it'll sit outside form -20°C to +60°C without drama, and at 28kg max you don't need a crane to mount it on a roof or a tripod — a couple of people can handle the lift.
One thing a lot of buyers don't think to ask about upfront: the high-gain directional antennas mean teh beam is narrow, so you absolutely need the PTZ to be calibrated on insallation or it'll miss drones at the edges of its field; we include a quick alignment guide with every unit.
For ordering, MOQ is one piece, and we typically ship with AC220V±10% input — confirm your mains voltge at quote stage, and we'll adjust if needed — and lead time runs about 30 working days give or take depending on spec customizations.
That 3km range applies when the target drone's signal source is as weak as 0.1W. For stronger signals, the effective range may be shorter, but in most real-world scenarios against consumer and prosumer drones, you'll get well over 3km.
No, it's strictly designed for 300MHz to 6GHz. That covers common drone control and video bands like 2.4GHz and 5.8GHz, plus some ISM bands, but it won't touch higher or lower frequencies.
Yes, we include both CE and RoHS certificates with every shipment. ISO compliance docs are also available on request — just ask your sales rep.
Standard MOQ is 10 units, and lead time runs about 15-20 working days for a custom batch. Smaller trial orders can sometimes be arranged — just talk to us.
Yes, it's designed to work continuously across that whole range. Just avoid direct sun exposure at +60°C for hours — the internal heatsink handles normal use fine.
