Introducing our high - performance 11 - seat electric bus, a flagship new energy vehicle designed for versatile applications across factory, station, wharf, airport, mall, hospital, school, hotel, golf course, amusement park, and scenic spot scenarios. This vehicle integrates advanced technology and robust construction, ensuring reliable performance and comfortable riding experience.
Power & Performance: Equipped with a 48V/5KW high - efficiency high - speed AC motor, this electric bus delivers smooth and powerful performance. The CMOS infinitely variable speed controller with automatic protection against slipping, downhill speed limitation, and personalized program design ensures safe and efficient operation. The MF 6*8V large - capacity deep - cycle traction battery provides a maximum mileage of ≥100km on a single charge, with a charging time of 8 - 12 hours using the auto high - frequency high - pulse charger (input AC 110V/220V 50hz, output DC 48V 25Ah, CE certified).
Structural & Safety Features: The frame - type high - strength steel structure chassis undergoes thermal spraying Zinc and dual anti - rust paint processing, ensuring durability and corrosion resistance. The body panel is made of high - quality steel plate with automotive sheet metal standard coating, offering impact resistance. The brake system adopts double - circuit four - wheel hydraulic brake (front disc rear drum) with mechanical parking (manual) for reliable stopping power. The minimum braking distance is ≤5m, and the gradeability reaches 30%, suitable for various terrains. Both front and rear suspension systems use multi - plate leaf spring and hydraulic damping cylinder type independent suspension, providing a stable and comfortable ride. The single - stage gear rack steering system with self - return function ensures precise and easy steering, with a minimum turning radius of 5500mm.
Comfort & Convenience: The one - piece seat system follows ergonomic principles, with emulation leather seats for comfortable seating. The black canvas ceiling is lightweight, waterproof, and UV - protective. The dashboard is equipped with ignition switch, electricity meter, direction selector switch, turning signals, brake lights, and horn meter for easy operation. The foldable high - strength organic glass front windshield and vacuum meridian mini car tyre (specification: 6.00 - 13T) enhance driving safety and comfort. Optional fittings include rain curtain, ECU electric power steering system, radio, and luxury leather seats to meet personalized needs.
Technical Parameters: The vehicle weighs 770KG, with dimensions L*W*H (MM) 4020×1520×1950. Wheelbase is 3260mm, minimum gap 170mm, front tread 1290mm, rear tread 1220mm. Maximum speed ranges from 24 - 30km/h, with a maximum back speed of 9 - 13km/h. It can seat 11 passengers, making it ideal for group transportation.
Customization & Certification: We offer comprehensive customization services, allowing customers to personalize products according to drawings and requirements, including OEM. The vehicle is ISO9001, ISO14001, OHSAS18001, and CE certified, with trademark and patent certificates, ensuring quality and compliance. It comes in multiple colors (Violet, Rose Red, Black, Yellow, Green, Blue, Red, White) to match different usage scenarios.
Warranty & Service: Enjoy a 1 - year warranty, with free - of - charge components provided by EXW cost - shipped term. Our full - weather post - sales service ensures timely support for any issues, making it a reliable choice for long - term use.
