Introducing our high - performance electric sightseeing vehicle, designed for versatile use in factories, stations, wharfs, airports, malls, hospitals, schools, hotels, golf courses, amusement parks, and scenic spots. This vehicle combines efficiency, comfort, and safety, making it an ideal choice for large - scale passenger transport and tour services.
Motor & Power System: The vehicle is powered by a 48V/5KW high - efficiency high - speed AC motor, ensuring strong performance and energy efficiency. The controller adopts a CMOS system with infinitely variable speed, featuring automatic protection against slipping, downhill speed limitation, and personalized program design for customized driving experiences.
Battery & Charger: It is equipped with an MF 6*8V large - capacity deep cycle traction battery, providing a maximum mileage of ≥100km on a single charge. The auto high - frequency high - pulse charger supports AC 110V/220V 50hz input and DC 48V 25Ah output, with CE certification for safety and reliability. Charging time ranges from 8 to 12 hours.
Chassis & Suspension: The frame - type chassis is constructed with high - strength steel, processed with thermal spraying zinc and dual antirust paint for durability. Both front and rear suspension systems utilize multi - plate leaf springs and hydraulic damping cylinders for independent suspension, ensuring a smooth ride even on uneven terrain. The motor - direct type integral rear axle includes main reduction and differential for efficient power transmission.
Brake & Steering: The dual - circuit four - wheel hydraulic brake system (front disc, rear drum) and mechanical parking (manual) ensure reliable stopping power, with a minimum braking distance of ≤5m. The single - stage gear rack steering system features self - return functionality for easy and precise control, enhancing driving safety and comfort.
Body & Interior: The cover panel is made of high - quality steel plate with stamping molding and automotive sheet metal standard coating, offering impact resistance. The seating system is a one - piece ergonomic design with emulation leather seats (or luxury leather as an option) for comfortable long - duration rides. The ceiling is black canvas, lightweight, waterproof, and UV - protective. The dashboard includes an ignition switch, electricity meter, direction selector switch, turn signals, brake lights, and horn meter for clear operation.
Light & Tyre: The light system includes headlights, front turn signal lamps, rear combination lights, a buzzer, and an electric horn for visibility and safety. Tyres are vacuum meridian mini car tyres (specification: 6.00 - 13T), providing strong load - bearing capacity and stable driving. The front windshield is foldable high - strength organic glass for convenience and safety.
Technical Parameters: The vehicle weighs 770KG, with dimensions L*W*H 4020×1520×1950mm. Wheelbase is 3260mm, minimum ground gap 170mm, front tread 1290mm, rear tread 1220mm, minimum turning radius 5500mm, gradeability 30%, maximum speed 24 - 30km/h, maximum back speed 9 - 13km/h, and seating capacity for 8 passengers. Container loading is 2 units per 20GP or 9 units per 40HQ.
Optional Fittings: Enhance your vehicle with a rain curtain, ECU electric power steering system, radio, or luxury leather seats to meet specific needs. The vehicle is available in multiple colors (Violet, Rose Red, Black, Yellow, Green, Blue, Red, White) and styles, suitable for various environments and aesthetic preferences.
Certifications: Our electric vehicle is certified with ISO9001, ISO14001, OHSAS18001, CE, trademark, and patent certificates, ensuring compliance with international quality and safety standards. A 1 - year warranty is provided for peace of mind, backed by reliable after - sales support.
