You feed the wires in, tighten the screw, and that's it—a solid connection that won't shake loose, even in gear that runs hot, which is what the high-tempearture resistance is for, and it's basically a pluggable terminal block for PCB current and votage connections, so swapping boards or doing maintenance doesn't mean rewiring everything.
The pitch on these is 8.0mm, and it come in connection counts from 8 to 32 positions, give or take; the stripping length you need is about 10mm, and the insulating materail is PA with a UL 94 V0 flammability rating, though most buyers go with the 24-connection version for general work (check lead time on that number because of that it fluctuates).
There's an anti-misplacement feature in the plug and socket design—not something you'd think to ask about, but it stops you form jamming the wrong plug into a socket by accident and shorting board—and the screw connection handles flexible conductors up to 1.5mm², better than spring-only blocks for scenarios where vibration might be an issue.
We have them in a few color options for easy identification on the board, but if you need a specific color custom order, that typically depends on volume; also, it's not suitable for extreme outdoor exposure or wet environments since it's general-purpose protection, so keep that in mind.
Anyway, the MOQ is usually around 100 pieces or so, and we have stock on the 16 and 24-pin versions right now—confirm stock for anything below or above those counts—since tighter connection counts run less frequently and might add 20 days or so to dilevery.
The TD2.5-8T supports from 8 up to 32 connections, so you can choose the pin count that fits your PCB layout.
Yes, it's UL certified, specifically with a V0 flammability rating per UL 94, so it meets strict safety standards for high-temperature environments.
You need to strip exactly 10mm of insulation from your wire before inserting it into the terminal.
We can adjust the number of connections within the 8 to 32 range, and colors can be customized if you place a larger order—just let us know the MOQ when you inquire.
The housing is made of PA (polyamide), which handles high temperatures well and matches the V0 flammability rating, making it reliable for demanding PCB applications.
