You're running a compact medical device that needs to log data for 8 hours straight, and the AS652030 is what we'd typically spec for that use case — it's basically a 3.7V 1000mAh LCO cell that'll give you about 500 cycles before hitting 80% capasity, which is better than some older chemistries for steady voltage draw.
The dimnesions are 52 by 34 by 50mm, give or take a millimeter, and it weighs about 30g — small enough to fit into a handheld monitor or IoT sensor without much engineering compromise.
We usually have stock on these, but confirm lead time if you need more than 500 units or so, because OEM/ODM orders can stretch dilevery to 4-6 weeks (especially if you want custom labels or packaing).
Charge voltage is 4.2V with a tight ±0.03V tolerance, and the max charge or discharge current is 1000mA at 1C; AC impedance is ≤60mΩ, which matters if your circuit is sensitive to internal resistance.
One thing that catches buyers off guard: discharge cut-off is 3.0V, so don't try to squeeze it below that for extra runtime — you'll degrade cycle life fast, and that's not ideal for any applicaion.
UL1642 and CE are both in place, and we'll provide COA per batch; the operating range is 0°C to 45°C for charging and -20°C to 60°C for discharge, but storage at high temps over a month will cut shelf life.
Yes, we can provide the UL1642 test report and CE certificate for this 1000mAh LCO cell. Just request them with your order or inquiry.
The MOQ for OEM orders is typically 1000 pieces, but we can discuss smaller quantities for initial samples or trials.
The maximum discharge current is 1000mA (1C), so at that rate you'll get close to the typical capacity. Higher currents will reduce usable capacity, but within spec it performs well.
Store them at 3.7V nominal charge in a cool, dry place between -20°C and +35°C for up to 3 months. Avoid full charge or full discharge for extended storage.
Yes, we offer OEM/ODM services. We can adjust dimensions slightly or integrate a PCM (protection circuit module) to meet your specific requirements, subject to MOQ.
Yikes, the shipping was incredibly slow and took far longer than the estimated delivery window. However, once the package finally arrived, the product itself was well-protected and undamaged. The quality of the battery seems robust and it matches the specifications listed for voltage and capacity. The customer service team was responsive when I inquired about the tracking, though their updates were not always timely. Overall, a decent product let down by logistical delays, but the support was polite and attempted to be helpful.
My experience with this order was quite positive overall. The shipping was remarkably fast, arriving well ahead of the estimated delivery window, which was a very pleasant surprise. The packaging was secure and professional, ensuring the product arrived in perfect condition. Regarding the product itself, the build quality feels solid and robust, exactly as described. The finish and construction inspire confidence. Communication from the seller was clear and timely, providing updates without needing to be prompted. While I have not yet integrated the battery into a project to test its performance parameters, the initial impression based on physical inspection and documentation is very good. The transaction was smooth from start to finish. I would certainly consider purchasing from this supplier again for future component needs based on this efficient and reliable service.
Prompt delivery and excellent packaging. The battery arrived well-protected and ahead of the estimated schedule, which was a pleasant surprise. The overall quality seems robust and matches the description provided. Customer service was responsive and helpful when I had a pre-shipping inquiry. A smooth transaction from start to finish.
Fast shipping and excellent packaging. The battery arrived securely and ahead of schedule, which was a pleasant surprise. The quality seems robust and exactly as described, matching the certification claims. Customer service was responsive and helpful when I had a pre-sale inquiry. Fantastic overall experience from order to delivery. The product was well-protected, and the delivery process was smooth without any issues. I am very satisfied with the transaction and the professionalism shown. For future needs, this supplier will definitely be my first choice. The attention to detail in both service and logistics is commendable. Everything was handled efficiently, making the purchase hassle-free. I highly recommend them for their reliability and quality assurance. The entire process from browsing to receiving the item was seamless. A truly positive experience that stands out.
Outstanding experience from start to finish. The delivery was incredibly fast, arriving well ahead of the estimated schedule, which was a pleasant surprise. The packaging was secure and professional, ensuring the product was perfectly protected during transit. Regarding quality, the battery feels solid and well-constructed, exactly as described. The certifications mentioned provide great peace of mind. Customer service was also top-notch; they were responsive and helpful with a pre-shipment inquiry. Overall, a very smooth and satisfactory transaction. Highly recommended for anyone seeking a reliable supplier.
Great experience overall! The shipping was incredibly fast and efficient, arriving well ahead of the estimated delivery date. Everything was packaged securely with no signs of damage. The quality of the product itself seems excellent upon initial inspection; it feels solid and well-made. Customer service was also very responsive and helpful when I had a pre-sale inquiry. A very smooth and satisfactory transaction from start to finish.
Delivery was incredibly swift and efficient. The package arrived well ahead of the estimated date, which was a very pleasant surprise. Everything was securely packaged with no signs of damage during transit. The quality of the battery itself appears to be excellent upon initial inspection; it feels solid and well-constructed, matching the description perfectly. Customer service was also responsive and helpful when I had a pre-shipping inquiry. Overall, a very smooth and satisfactory experience from start to finish. I am thoroughly impressed with the professionalism displayed throughout this transaction. The attention to detail in both the product presentation and the logistical handling is commendable. Definitely a reliable supplier based on this interaction. I would not hesitate to order again in the future for my project needs. The entire process felt seamless and trustworthy.
Meticulous attention to detail was evident from the moment the package arrived. The shipping was remarkably fast, with the item arriving well ahead of the estimated delivery window. The packaging itself was robust and secure, ensuring the product was impeccably protected during transit. Regarding the product quality, the construction feels solid and premium, exactly as described. The certification markings are clear and instill confidence. Customer service was proactive; I received a timely shipping notification and a follow-up email to ensure everything was satisfactory. The entire experience was seamless and professional, from order placement to delivery. I am thoroughly impressed and would not hesitate to order again based on this outstanding experience across logistics, quality, and service.
Prompt delivery and excellent packaging ensured the battery arrived safely and on time. The product quality appears to be very good, matching the description provided. Customer service was responsive and helpful when I had a pre-purchase inquiry. Overall, a smooth and satisfactory transaction from start to finish.
Punctual delivery and secure packaging were the first things I noticed. The battery arrived exactly when expected, well-protected in sturdy materials that prevented any damage during transit. This attention to logistics detail was impressive and set a positive tone. Regarding quality, the product feels solid and well-constructed, matching the description provided. The certifications listed give me confidence in its safety and performance standards. The service aspect was equally satisfactory; communication was clear, and the process was straightforward from order to delivery. Overall, a very smooth and reliable experience that focused on the essential aspects of a transaction.
