CE/FDA Certified SAB-500 Ultrasound B Scanner for Ophthalmology Clinics and Hospitals

The SAB-500 Ophthalmic Ultrasound B Scanner is a sophisticated diagnostic instrument designed for comprehensive eye examinations. This advanced equipment combines both A-scan and B-scan modalities to provide ophthalmologists with detailed information about ocular structures.

With its 10MHz standard frequency (20MHz optional) probe, the scanner delivers high-resolution images of the anterior chamber, lens, vitreous body, and retina. The magnetic-driven probe operates noiselessly, ensuring patient comfort during examinations.

The device features multiple specialized modes including vitreous body enhancement and retina observation, enabling accurate diagnosis of various ocular conditions such as vitreous opacity, retinal detachment, and ocular tumors. The sector scanning technology provides wide-angle views of the eye's internal structures.

For cataract surgeons, the integrated IOL calculation system includes six popular formulas (SRK-II, SRK-T, HOFFER-Q, HOLLADAY, BINKHORST-II, HAIGIS) to determine the optimal intraocular lens power. The A-scan mode precisely measures anterior chamber depth, lens thickness, and axial length with ±0.05mm accuracy.

The 15-inch LCD display presents images in 256 gray scales with optional pseudo-color processing. The system stores up to 10 scanning results per eye and allows for movie review of 100 images in AVI/JPG formats. Built-in battery provides 4 hours of continuous operation for mobile use.
