S8 Biphasic Defibrillator Monitor with 360J Energy Selection for Emergency Cardiac Care

The S8 Defibrillator Monitor represents a significant advancement in emergency cardiac care technology. Designed for both speed and efficiency, this life-saving device eliminates complex operations to maximize rescue effectiveness during critical moments.

Featuring 25 types of energy selection that can be completed in just 1 second, the device ensures optimal response times. The simplified three-step defibrillation process (energy selection-charge-discharge) and dedicated 12-lead monitoring interface button make operation intuitive for medical professionals. The innovative 2-in-1 electrode paddles system includes both adult and pediatric sizes, providing versatility in emergency situations.

With energy selection up to 360J, the S8 is particularly effective for patients with high defibrillation thresholds, including those with myocardial infarction, obesity, or high impedance. The device covers an impedance range of 20-250Ω, making it suitable for various patient types. Advanced biphasic truncated exponential (BTE) waveform technology with automatic impedance compensation ensures higher defibrillation success rates.

The defibrillator's rugged construction meets IP44 protection standards, making it resistant to shocks, falls, and water splashes from all directions - ideal for use in challenging outdoor environments. A large-capacity lithium battery supports fast charging and provides over 420 discharge cycles to meet clinical demands.

Diagnostic features include an 80mm thermal printer for clear waveform documentation and extensive data storage capabilities. The device supports 240 minutes of AED voice recording storage, with each patient's record storable for up to 60 minutes. Comprehensive event review functions allow for detailed trend analysis and data retrieval.

The integrated network solution enables efficient access to patient information when needed, significantly improving clinical workflow. With manual, automatic, and power-on self-test functions, the S8 ensures readiness for emergency situations.
