Factory Supply Insert Spring Hose Clamp with Non-Perforated Band and Hex Head Screw

The Insert Spring Hose Clamp is engineered to meet DIN3017 standards, providing constant tension that automatically compensates for hose shrinkage. This feature ensures a secure fit and prevents leakage, particularly in low-temperature environments. It is also compatible with thermoplastic hoses, making it versatile for various industrial applications.

Constructed with a non-perforated band measuring 12mm in width and 0.70-0.80mm in thickness, the clamp offers enhanced durability and strength. The screw features a 7mm hex head for easy installation and reliable fastening. The clamp is available in multiple clamping ranges, from 16-27mm to 90-110mm, catering to different hose sizes and requirements.

Made from high-quality stainless steel, the Insert Spring Hose Clamp exhibits excellent corrosion and oxidation resistance. This ensures a long service life even in humid, corrosive, or high-temperature conditions. The materials used include AISI 430SS and AISI 304SS for the band and housing, with options for zinc-plated steel or stainless steel screws, depending on the model.

The clamp's design emphasizes strength and stability, achieved through precise engineering and processing. It firmly secures pipelines, preventing leaks and displacements, thereby enhancing the safety and reliability of the system. Customization options include stamping logos and sizes on the band as per customer specifications.

This product is ideal for heavy-duty applications and is supplied in various packaging options. It is designed for industrial use, offering reliable performance and ease of installation. For detailed specifications and clamping range data, refer to the provided parameters.
